Thermoplastic hydraulic hose and fittings Parts
























Compare Thermoplastic hydraulic hose and fittings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | A dimension MM | Hose cut off factor IN | Hose cut off factor MM | Product length in | Product length mm |
|---|---|---|---|---|---|
| 9MH08-22SL01LINRK9 | 84.300 | 1.760 | 44.700 | 2.810 | 71.374 |
| 9MH08-22SL01 | 84.300 | 1.760 | 44.700 | 3.320 | 84.300 |
| 9MH08-08R100 | 75.200 | 1.400 | 35.600 | 2.960 | 75.184 |
| 9MH08-08B000 | 71.600 | 1.260 | 32.000 | 2.820 | 71.628 |
| 9MH06-20JS00 | 67.500 | 1.350 | 34.200 | 2.660 | 67.564 |
| 9MH04-18JS00 | 60.200 | 1.350 | 34.200 | 2.370 | 60.198 |
| 9MH04-10N040 | 77.200 | 1.950 | 49.600 | 3.040 | 77.216 |
| 9MH04-04V400 | 57.000 | 1.160 | 29.400 | 2.240 | 56.896 |
| 9MH04-04R100 | 56.400 | 1.140 | 28.800 | 2.220 | 56.388 |
| 9MH04-04B0B0 | 49.400 | 0.860 | 21.800 | 2.370 | 60.198 |
| 9MH04-04B000 | 56.800 | 1.150 | 29.200 | 2.240 | 56.896 |
| 9M308-15N000 | 85.300 | 1.800 | 45.700 | 3.360 | 85.344 |
| 9M306-16BM01 | 94.500 | 2.410 | 61.100 | 4.370 | 110.998 |
| 9M305-20SS00 | 61.600 | 1.240 | 31.500 | 2.430 | 61.722 |
| 9M305-16SL00 | 57.600 | 1.080 | 27.500 | 2.270 | 57.658 |
| 9M305-14BM90 | 63.500 | 1.320 | 33.400 | 2.780 | 70.612 |
| 9M305-12BM00 | 60.600 | 1.200 | 30.500 | 2.790 | 70.866 |
| 9M304-16JL00 | 60.700 | 1.300 | 33.100 | 2.390 | 60.706 |
| 9M304-14JL00 | 59.500 | 1.260 | 31.900 | 2.340 | 59.436 |
| 9M304-10N090 | 60.400 | 1.290 | 32.800 | 2.760 | 70.104 |
| 9M303-08N000 | 60.300 | 1.520 | 38.500 | 2.370 | 60.198 |
| 9M302-02V490 | 44.900 | 1.170 | 29.600 | 2.090 | 53.086 |
| 9CV06-065502-0 | — | 1.600 | 40.640 | — | — |
| 9CV04-045400-0 | — | 1.400 | 35.560 | — | — |
Common to all listed parts
| Thread sealant | No |
