Kinetix & Legacy Servo Drives, 2090 Motion Cables Parts
Compare Kinetix & Legacy Servo Drives, 2090 Motion Cables
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | AWG size | Cable length | Nominal cross section conductor (AWG) | Nominal cross section conductor | Drive-end Connector Type |
|---|---|---|---|---|---|
| 2090-CSBM1DG-14AF45 | 14 AWG | 45 m | 4.1 | 2.08 | — |
| 2090-CSBM1DG-14AF28 | 14 AWG | 28 m | 4.1 | 2.08 | — |
| 2090-CSBM1DG-14AF27 | 14 AWG | 27 m | 4.1 | 2.08 | Drive-End, Flying Lead, hybrid |
| 2090-CSBM1DG-14AF19 | 14 AWG | 19 m | 4.1 | 2.08 | Drive-End, Flying Lead, hybrid |
| 2090-CSBM1DF-14AF23 | 14 AWG | 23 m | 4.1 | 2.08 | Flying Lead at 5500 Drive End |
| 2090-CSBM1DF-14AF21 | 14 AWG | 21 m | 4.1 | 2.08 | Drive-end, flying-lead |
| 2090-CSBM1E1-06AF09 | 6 AWG | 9 m | 26.25 | 13.3 | — |
| 2090-CSBM1E1-06AF03 | 6 AWG | 3 m | 26.25 | 13.3 | Extension Receptor |
| 2090-CSBM1DF-18AA19 | 18 AWG | 19 m | 1.62 | 0.82 | Flying Lead at 5500 Drive End |
| 2090-CSBM1E1-10AF01 | 10 AWG | 1 m | 10.38 | 5.26 | — |
| 2090-CSBM1DG-10AF01 | 10 AWG | 1 m | 10.38 | 5.26 | — |
| 2090-CSBM1DG-18AF02 | 18 AWG | 2 m | 1.62 | 0.82 | Drive-End, Flying Lead, hybrid |
| 2090-CSBM1DF-18AA33 | 18 AWG | 33 m | 1.62 | 0.82 | Flying Lead at 5500 Drive End |
| 2090-CSBM1DF-18AA32 | 18 AWG | 32 m | 1.62 | 0.82 | Flying Lead at 5500 Drive End |
| 2090-CSBM1DF-18AA26 | 18 AWG | 26 m | 1.62 | 0.82 | Flying Lead at 5500 Drive End |
| 2090-CSBM1DF-18AA28 | 18 AWG | 28 m | 1.62 | 0.82 | Flying Lead at 5500 Drive End |
| 2090-CSBM1DF-18AA23 | 18 AWG | 23 m | 1.62 | 0.82 | — |
| 2090-CSBM1DF-18AA22 | 18 AWG | 22 m | 1.62 | 0.82 | Flying Lead at 5500 Drive End |
| 2090-CSBM1DG-14AA29 | 14 AWG | 29 m | 4.1 | 2.08 | Drive-End, Flying Lead, hybrid |
| 2090-CSBM1DG-14AA18 | 14 AWG | 18 m | 4.1 | 2.08 | Drive-End, Flying Lead, hybrid |
| 2090-CSBM1DF-18AA36 | 18 AWG | 36 m | 1.62 | 0.82 | Flying Lead at 5500 Drive End |
| 2090-CSBM1DF-18AA43 | 18 AWG | 43 m | 1.62 | 0.82 | Drive-end, flying-lead |
| 2090-CSBM1DG-14AA16 | 14 AWG | 16 m | 4.1 | 2.08 | Drive-End, Flying Lead, hybrid |
| 2090-CSBM1DG-14AA08 | 14 AWG | 8 m | 4.1 | 2.08 | Drive-end, long flying-leads |
Common to all listed parts
| Lifecycle | Active |
| Repair options available | No |
| Accessory component | Cable |
| Cable type | Single motor power with brake wires |
| Color cable code | RAL2003 |
| Colour outer sheath | Orange |
| Conductor material | Copper |
| Conductor surface | Tinned |
