Medium payload class Parts
Compare Medium payload class
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Maximum payload | Rated payload | Maximum reach | A2 | A3 |
|---|---|---|---|---|---|
| U1423926 | 62 kg | 50 kg | 2101 mm | 175 °/s | 175 °/s |
| U1423937 | 62 kg | 50 kg | 2101 mm | 175 °/s | 175 °/s |
| U1423927 | 37 kg | 30 kg | 2101 mm | 165 °/s | 180 °/s |
| U1426210 | 62 kg | 50 kg | 2101 mm | 175 °/s | 175 °/s |
| U1427048 | 37 kg | 30 kg | 2101 mm | 165 °/s | 180 °/s |
| U1427049 | 37 kg | 30 kg | 2101 mm | 165 °/s | 180 °/s |
| U1426216 | 37 kg | 30 kg | 2101 mm | 165 °/s | 180 °/s |
| U1427595 | 85 kg | 70 kg | 2101 mm | 158 °/s | 160 °/s |
| U1427622 | 85 kg | 70 kg | 2101 mm | 158 °/s | 160 °/s |
| U1427612 | 62 kg | 50 kg | 2101 mm | 175 °/s | 175 °/s |
| U698702 | 30 kg | 30 kg | 2429 mm | 102 °/s | 128 °/s |
| U698703 | 30 kg | 30 kg | 2429 mm | 102 °/s | 128 °/s |
| U704307 | 30 kg | 30 kg | 2033 mm | 126 °/s | 140 °/s |
| U1427604 | 85 kg | 70 kg | 2101 mm | 158 °/s | 160 °/s |
| U4620540 | 155 kg | 120 kg | 2702 mm | 100 °/s | 120 °/s |
| U4620541 | 155 kg | 120 kg | 2702 mm | 100 °/s | 120 °/s |
| U1426377 | 85 kg | 70 kg | 2101 mm | 158 °/s | 160 °/s |
| U1428348 | 62 kg | 50 kg | 2501 mm | 158 °/s | 175 °/s |
| U1429099 | 62 kg | 50 kg | 2101 mm | 175 °/s | 175 °/s |
| U707114 | 60 kg | 60 kg | 2033 mm | 102 °/s | 128 °/s |
| U706808 | — | 30 kg | 2429 mm | 102 °/s | 128 °/s |
| U706617 | — | 30 kg | 2429 mm | 102 °/s | 128 °/s |
| U706807 | — | 30 kg | 2429 mm | 102 °/s | 128 °/s |
| U706811 | — | 30 kg | 2429 mm | 102 °/s | 128 °/s |
Common to all listed parts
| Number of axes | 6 |
| Ambient temperature during stor./transp. | -40 °C to 60 °C (233 K to 333 K) |
