Danfoss orbital motor quick selector Parts
Compare Danfoss orbital motor quick selector
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Motor size | Geometric displacement [cm3/r [in3/r]] | Mounting flange type | Main port dimension | Drain Port Dimension |
|---|---|---|---|---|---|
| 11251114 | 315 | 326.3 [19.91] | 4 Bolt - Square | G 3/4, 4 x M10 block mounting threads | G 3/8 |
| 11249041 | 400 | 397.2 [24.24] | 6 Bolt - Magneto | G 3/4 | G 1/4 |
| 11247365 | 400 | 400.9 [24.46] | 4 Bolt - Wheel | 1 5/16 - 12 UN-2B SAE O-Ring port, | 9/16 - 18 UNF-2B O-Ring port |
| 11246115 | 500 | 523.6 [31.95] | 4 Bolt - Wheel | 1 1/16 - 12 UN-2B SAE O-Ring port, - | 9/16 - 18 UNF-2B O-Ring port |
| 11244088 | 500 | 499.6 [30.49] | 4 Bolt - Square | 1 5/16 - 12 UN-2B SAE O-Ring port, | 9/16 - 18 UNF-2B O-Ring port |
| 11242279 | 630 | 629.1 [38.39] | 4 Bolt - Wheel | G 1, 4 x M12 block mounting threads | G 1/4 |
| 11241593 | 630 | 629.1 [38.39] | 4 Bolt - C | 1 5/16 - 12 UN-2B SAE O-Ring port, | 9/16 - 18 UNF-2B O-Ring port |
| 11237689 | 160 | 158.0 [9.64] | 4 Bolt - C | 1 1/16 - 12 UN-2B SAE O-Ring port, | 7/16-20 UNF-2B O-Ring port |
| 11233625 | 160 | 161.1 [9.83] | 4 Bolt - Wheel | G 3/4, 4 x M10 block mounting threads | G 1/4 |
Common to all listed parts
| Delete Model Code | Yes |
| Proposition 65 | Cancer and Reproductive Harm |
| Valve system | Disc valve with valve drive |
| Orbital gearwheel set type | Geroler |
| Main port style | Sideport - staggered |
| Special features hardware | Standard |
| Special Features Assembly | Standard |
| Dust seal | Standard |
