Wago 756-5312/060-015
Sensor/Actuator cable; M12A plug; angled; 5-pole; Length: 1.5 m
- MPN
- 756-5312/060-015
Price and lead time confirmed within 1 business day
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
What is the Wago 756-5312/060-015?
Short description:
PUR, halogen-free
Suitable for drag chains
High resistance to microbes, hydrolysis, oil, chemicals and UV radiation
High chemical resistance
Cable used: UL listed
Specifications
Technical data - General information
| Operating voltage | 250 VAC/DC |
| Operating current | 4 A |
| Rated impulse withstand voltage | 1.5 kV |
| Insulation resistance | >109 Ω |
| Contact resistance | 10 mΩ |
| Conductor resistance | ≤ 60 Ω/km |
| Pollution degree | 3 per VDE 0110 |
| Protection type | IP67 |
| Ambient (operating) temperature (static) | -50 … +90 °C |
| Ambient (operating) temperature (dynamic) | -25 … +90 °C |
Technical data - Drag chain compatible
| Bending radius | 10 x cable diameter (min.) |
| Bending cycles | 2 Mio. |
| Acceleration (min.) | 5 |
| Travel speed (max.) | 3.33 |
| Travel path (horizontal) max. | 5 |
| Travel path (vertical) max. | 2 |
| Torsional capacity | 180 |
Technical data - Cable
| Cable length | 1.5 m |
| Type code | LiF9YH-11YH or LiF9YC11YFHF |
| Conductor configuration | Bare copper wire, fine-stranded (42 x 0.1 mm) |
| Conductor insulation | PP9Y (halogen-free) |
| Sheath material | Polyurethane (PUR), halogen-free per DIN VDE 0472 Part 815, flame resistant per IEC 332-2, self-extinguishing |
| Sheathed cable color | black |
Technical data - Connector
| Connection type | M12 plug - free end |
| Pole number | 5 |
| Cable connection direction to mating direction | 90 ° |
| Connector interface coding (cable/adapter) 1 1 | A-coded |
| Housing material | Polyurethane (PUR) |
| Contact material | CuSn |
| Tightening torque | 1 Nm |
Commercial data
| PU (SPU) | 1 pcs |
| Packaging type | Box |
| Country of origin | HU |
| GTIN | 4045454942359 |
| Customs tariff number | 85444290900 |
Product Classification
| UNSPSC | 26121604 |
| eCl@ss 10.0 | 27-06-03-11 |
| eCl@ss 9.0 | 27-06-03-11 |
| ETIM 9.0 | EC001855 |
| ETIM 10.0 | EC001855 |
| ECCN | NO US CLASSIFICATION |
Environmental Product Compliance
| RoHS Compliance Status | Compliant,With Exemption |
| RoHS Exemption | 6(c) |
| SCIP notification number (Austria) | 2311cec6-93d8-4415-89a4-777d01d4ffaa |
| SCIP notification number (Belgium) | 2a1d2944-933a-480c-b0e7-966cde73c2d1 |
| SCIP notification number (Bulgaria) | f8a68721-47bd-40c2-81b0-31b1d919814c |
| SCIP notification number (Czech Republic) | 5a75bd69-3259-4d56-bd32-9bc4a81ca78c |
| SCIP notification number (Denmark) | c0e3760b-eb5a-438b-bd53-ccb7dd0a9978 |
| SCIP notification number (Finland) | 88c6c55c-7101-43ff-9b94-abc89a11116c |
| SCIP notification number (France) | 856cc39f-a1e2-4994-b605-feca6721bdde |
| SCIP notification number (Germany) | e8385445-1482-4cc8-9d05-3d40aaa07dd4 |
| SCIP notification number (Hungary) | 33d1ceb0-3094-42a7-b6b0-27079edbe174 |
| SCIP notification number (Italy) | d76b567b-dae5-43cc-a99d-c209056e0dc6 |
| SCIP notification number (Netherlands) | 7006acad-bf14-4f36-a1ed-43d7f27f28c6 |
| SCIP notification number (Poland) | 6805a639-cb99-4273-b455-49f825ebb3c3 |
| SCIP notification number (Romania) | 1cb14d70-bbfd-46b5-974c-e7ad0c6d8ece |
| SCIP notification number (Sweden) | a40234ae-59a5-476a-b510-df6bd03d85a2 |
No matching specifications
756-5312/060-015: frequently asked questions
When can 756-5312/060-015 be shipped?
756-5312/060-015 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 756-5312/060-015 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 756-5312/060-015 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 756-5312/060-015, subject to availability and destination.
