Schneider Electric TSXDSY08R5 – discrete output module Modicon Premium - 8 O relay
Discontinued by Schneider Electric — we can still source the original TSXDSY08R5 (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Modicon Premium |
| Lifecycle | Discontinued |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| UPC / EAN | 3389110725803 |
| Datasheet | Manufacturer datasheet ↗ |
Shipping & availability
Can I still buy the TSXDSY08R5 now that it is discontinued?
Yes. Schneider Electric has discontinued the TSXDSY08R5, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.
When can TSXDSY08R5 be shipped?
TSXDSY08R5 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up TSXDSY08R5 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for TSXDSY08R5 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for TSXDSY08R5, subject to availability and destination.
Schneider Electric TSXDSY08R5 — discrete output module Modicon Premium - 8 O relay. Discontinued by Schneider Electric. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.
Specifications
Main
| Range of product | Modicon Premium Automation platform |
| Product or component type | Discrete output module |
| Discrete output number | 8 |
| Discrete output type | Relay not protected |
| Discrete output voltage | 12...24 V DC conforming to EN/IEC 61131-2 10...34 V; 24...240 V AC conforming to EN/IEC 61131-2 20...264 V |
Complementary
| [Ith] conventional free air thermal current | 3 A |
| Response time | < 10 ms (deactivation); < 8 ms (activation) |
| Contacts type and composition | 1 NO |
| Output overvoltage protection | DC inductive, by discharge diode on each preactuator; AC inductive, by RC circuit MOV (ZNO) on each preactuator |
| Output overload protection | 1 external fuse per channel or group of channel fast blow |
| Short-circuit protection | 1 external fuse per channel or group of channel fast blow |
| isalotion resistance | > 10 MOhm 500 V |
| Power dissipation | (0.25 W + 0.2 W x No of outputs at state 1) |
| Electrical durability | 1000000 cycles DC-12 24 W 24 V resistive; 1000000 cycles DC-3 24 W 24 V inductive; 2000000 cycles DC-3 10 W 24 V inductive; 300000 cycles DC-12 40 W 24 V resistive; 100000 cycles AC-14 220 VA 220 V inductive; 100000 cycles AC-15 220 VA 220 V inductive; 1000000 cycles AC-12 110 VA 110 V resistive; 1000000 cycles AC-12 220 VA 220 V resistive; 1000000 cycles AC-12 50 VA 48 V resistive; 1000000 cycles AC-14 110 VA 220 V inductive; 1000000 cycles AC-15 110 VA 220 V inductive; 150000 cycles AC-14 110 VA 110 V inductive; 150000 cycles AC-15 110 VA 110 V inductive; 1500000 cycles AC-14 50 VA 110 V inductive; 1500000 cycles AC-15 50 VA 110 V inductive; 2000000 cycles AC-14 24 VA 48 V inductive; 2000000 cycles AC-15 24 VA 48 V inductive; 3000000 cycles AC-14 50 VA 220 V inductive; 3000000 cycles AC-15 50 VA 220 V inductive; 500000 cycles AC-12 110 VA 48 V resistive; 500000 cycles AC-12 220 VA 110 V resistive; 500000 cycles AC-14 24 VA 24 V inductive; 500000 cycles AC-15 24 VA 24 V inductive; 5000000 cycles AC-14 10 VA 110 V inductive; 5000000 cycles AC-14 10 VA 220 V inductive; 5000000 cycles AC-14 10 VA 48 V inductive; 5000000 cycles AC-15 10 VA 110 V inductive; 5000000 cycles AC-15 10 VA 220 V inductive; 5000000 cycles AC-15 10 VA 48 V inductive; 700000 cycles AC-12 50 VA 24 V resistive |
| Marking | CE |
| Electrical connection | Screw terminal block |
| Current consumption | 55 mA at 5 V DC; 70 mA at 24 V DC rack |
| Module format | Standard |
| Net weight | 0.33 kg |
Environment
| Dielectric strength | 2000 V 50/60 Hz 60 s |
| Standards | UL 508; 73/23/EEC; 89/336/EEC; CSA C22.2 No 213 Class I Division 2 Group B; CSA C22.2 No 213 Class I Division 2 Group C; IEC 61131-2; CSA C22.2 No 213 Class I Division 2 Group A; 92/31/EEC; CSA C22.2 No 213 Class I Division 2 Group D; CSA C22.2 No 142; 93/68/EEC |
| Product certifications | BV; GL; ABS; DNV; RINA; LR; RMRS |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -25…70 °C |
| Relative humidity | 10…95 % without condensation for operation; 5…95 % without condensation for storage |
| Operating altitude | 0...2000 m |
| Protective treatment | TC |
| IP degree of protection | IP20 |
| Pollution degree | 2 |
