RXZ400Mounting accessory, Harmony Electromechanical Relays, maintaining clamp, for RXM sockets, metal
Schneider Electric RXZE2M2N
Harmony, Socket, Harmony Relay, RXZ, mixed contact, 22.5 mm, 2 C/O, 10 A
- MPN
- RXZE2M2N
- Category
- Harmony Electromechanical Relays
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Schneider Electric RXZE2M2N?
Schneider Electric Harmony, Socket, Harmony Relay, RXZ, mixed contact, 22.5 mm, 2 C/O, 10 A, manufacturer part number RXZE2M2N. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Range of product | Harmony Electromechanical Relays |
| Product compatibility | Plug-in relay RXM with 2 C/O contact |
| Device short name | RXZ |
| [Ith] conventional free air thermal current | 10 A |
| Product or component type | Socket |
| Contacts type and composition | 2 C/O |
| [Ui] rated insulation voltage | 250 V |
| [Ue] rated operational voltage | < 250 V |
| Connections - terminals | Connector, 1 x 0.2...1 x 2.5 mm² (AWG 24...AWG 14) flexible with cable end, Connector, 2 x 0.2...2 x 1.5 mm² (AWG 24...AWG 16) flexible with cable end, Connector, 1 x 0.5...1 x 2.5 mm² (AWG 20...AWG 14) solid without cable end, Connector, 2 x 0.5...2 x 1.5 mm² (AWG 20...AWG 16) solid without cable end |
| Tightening torque | < 0.8 N.m for M3 screw(s) |
| Fixing mode | By screw (panel), Clip-on (35 mm symmetrical DIN rail) |
| [Uimp] rated impulse withstand voltage | 3.6 kV |
| Overvoltage category | III |
| Pollution degree | 3 |
| Sale per indivisible quantity | 10 |
| Width | 22.5 mm |
| Net weight | 0.056 kg |
| Dielectric strength | 2500 V |
| Standards | IEC 61984 |
| Marking | CE |
| Ambient air temperature for storage | -40…85 °C |
| Ambient air temperature for operation | -40…55 °C |
Packaging
| Package 1 | 1 PCE, 7.5 cm × 2.2 cm × 3 cm (L × W × H), 37 g |
| Package 2 | 10 BB1, 11.8 cm × 6.8 cm × 8.5 cm (L × W × H), 372 g |
| Package 3 | 180 S02, 40 cm × 30 cm × 15 cm (L × W × H), 6696 g |
RXZE2M2N: frequently asked questions
When can RXZE2M2N be shipped?
RXZE2M2N is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up RXZE2M2N in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for RXZE2M2N and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for RXZE2M2N, subject to availability and destination.
