Schneider Electric NSYSPLA100
Set of 2 uprights for mount. hor.support plate or 19"chassis in PLAencl.H1000mm
- MPN
- NSYSPLA100
- EAN
- 3606480194559
- Category
- PanelSeT PLA
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Schneider Electric NSYSPLA100?
Galvanised steel upright for PanelSeT PLA enclosures The nominal height is 1000mm The depth is 70mm The uprights are used for mounting chassis and fixing wiring accessories Mounting is adjustable in depth every 50mm with caged nuts Fixed by fixing element on sides of enclosure location Cut-out dimension is 11 x 13mm The product is made of fixing elements, 1 right upright and 1 left upright
Specifications
Specifications
| Range | PanelSeT |
| Accessory / separate part category | Mounting accessory |
| Product or component type | Upright |
| device application | Multi-purpose |
| enclosure nominal dimensions | - H: 1000 mm D: 320 mm, - H: 1000 mm D: 420 mm |
| Mounting support | Intermediate support in the 2-door enclosures |
| Range compatibility | PanelSeT PLA |
| Device composition | Fixing elements, 1 right upright, 1 left upright |
| Material | Galvanised steel |
| Fixing mode | By fixing element - sides of enclosure location |
| Adjustment | Adjustable in depth every 50 mm with caged nuts |
| Height | Nominal: 1000 mm |
| Depth | 70 mm |
| Cut-out dimensions | 11 x 13 mm |
Packaging
| Package 1 | 1 PCE, 83.000 cm × 7.000 cm × 3.000 cm (L × W × H), 1.416 kg |
| Package 2 | 40 PAL, 120.000 cm × 37.500 cm × 29.000 cm (L × W × H), 56.640 kg |
