What is the Schneider Electric AP9640?
The Network Management Card 3 enables essential and secure remote monitoring and management of a UPS, giving you mission-critical visibility. The high-speed processor provides a fast and powerful experience offering Gigabit Ethernet connectivity and simultaneous multiple user logins to the easy-to-use web user interface or Command Line Interface. Take proactive actions and troubleshoot easily with detailed data and event logging for timely resolution. Advanced technology and features keep sensitive data secure with the newest and best-in-class security compliance. The Network Management Card includes a 1-year Secure NMC Subscription which provides access to the latest firmware which is independently certified to the IEC 62443-4-2 standard. Integrates with EcoStruxure IT for efficient management of your equipment, PowerChute Network Shutdown for graceful shutdown, unattended start-up and VM migration options for disaster avoidance and business continuity, and with other SNMP-enabled systems.
Specifications
Specifications
| Range of product | Network Management Cards |
| Range compatibility | Galaxy VM, Galaxy VX, Symmetra PX, Easy UPS 3M Advanced, Easy UPS 3-Phase Modular, Galaxy PX, Galaxy 3L Pro, Smart-UPS, Smart-UPS Ultra, Smart-UPS Online, Smart-UPS Modular Ultra, Smart-UPS Battery Systems, Back-UPS SX3, Refurbished Smart-UPS |
| Product or component type | Device monitoring and management |
| Provided equipment | Micro-USB cable, Installation manual |
| Number of input phases | 1, 3 |
| Standards | EN 55024, BS EN 55024, EN 61000-4-2, BS EN 61000-4-2, EN 61000-4-3, BS EN 61000-4-3, EN 61000-4-4, BS EN 61000-4-4, EN 61000-4-5, BS EN 61000-4-5, EN 61000-4-6, BS EN 61000-4-6, EN 61000-4-8, BS EN 61000-4-8, EN 61000-4-11, BS EN 61000-4-11, EN 55035, BS EN 55035, EN 62040-2, BS EN 62040-2, EN 61326-2, BS EN 61326-2, ICES-003 class A, VCCI class A, EN 61000-6-3, BS EN 61000-6-3, EN 55032:class A, BS EN 55032:class A |
| Net weight | 0.08 kg |
| Width | 12.1 cm |
| Height | 3.8 cm |
| Depth | 11.4 cm |
| Product certifications | FCC Class A, AS/NZS, AS/NZS 3548 (C-Tick) class A, FCC part 15 class A, GOST, UK PSTI |
| Storage Relative Humidity | 0…95 % |
| Relative humidity | 0…95 % |
| Ambient air temperature for storage | -15…65 °C |
| Ambient air temperature for operation | -5…45 °C |
| Storage altitude | 0…15240 m |
| Operating altitude | 0...10000 ft |
| Communication network type | 10/100/1000BASE-T |
| Authentication | Radius, Lightweight Directory Access Protocol (LDAP) |
| Communication port protocol | HTTP over secure sockets, Layer (HTTPS), SSH, FTP, HTTP, SNMP, DHCP, BOOTP (Bootstrap Protocol), TCP/IP |
Packaging
| Package 1 | 1 PCE, 23.5 cm × 15.9 cm × 5.1 cm (L × W × H), 0.34 kg |
