Schneider Electric 170DNT11000

Modicon Momentum - Profibus DP communication adaptor - bus manager PLC

MPN
170DNT11000
EAN
3595861000353
Price and lead time confirmed within 1 business day

Discontinued by Schneider Electric — we can still source the original 170DNT11000 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Schneider Electric parts? We buy surplus →

What is the Schneider Electric 170DNT11000?

This product is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This Profibus DP communication adaptor supports ring and multidrop topology. The adaptor offers twisted pair transmission support medium and 9.6Mbps to 12Mbps data rate. It is equipped with 2 x 9-way SUB-D connectors for electrical connection. It supports 9.6kbps to 12Mbps communication rate with twisted pair cable media and distance of 1200m (4000ft). It is an IP20 rated product. It weighs 0.07kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, UL and CSA. Momentum is a flexible, modular family of fundamental components that easily snap together and can be configured for a wide range of distributed I/O and control applications. The Profibus DP communication adapter for the Momentum I/O product line provides a direct connection to the Profibus DP communication network for the full family of Momentum I/O modules. Discontinued by Schneider Electric. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of productModicon Momentum automation platform
Product or component typeProfibus DP communication adaptor
Method of accessMaster/slave

Complementary

Communication port protocolProfibus DP
AddressingSwitch selectable
Fail stateFail safe
Transmission support mediumTwisted pair
Transmission rate9.6...12 Mbit/s
TopologyRing; Multidrop
Control parameterCRC-16
Net weight0.07 kg

Environment

IP degree of protectionIP20
Protective treatmentTC
MarkingCE

Downloads & documentation

Official documents from Schneider Electric, downloaded directly from the manufacturer.

Data sheets & manuals

170DNT11000: frequently asked questions

Can I still buy the 170DNT11000 now that it is discontinued?

Yes. Schneider Electric has discontinued the 170DNT11000, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can 170DNT11000 be shipped?

170DNT11000 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 170DNT11000 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 170DNT11000 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 170DNT11000, subject to availability and destination.
