Schneider Electric 170ADM69051

Discrete I/O module Modicon Momentum - 10I / 8O solid state

MPN
170ADM69051
EAN
3595860019271
Price and lead time confirmed within 1 business day

Discontinued by Schneider Electric — we can still source the original 170ADM69051 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Schneider Electric parts? We buy surplus →

What is the Schneider Electric 170ADM69051?

This I/O module is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This discrete triac I/O base AC module offers 1 group of 10 inputs and 1 group of 8 outputs with positive discrete input logic. It is a module with discrete input voltage of 120V AC and discrete output voltage ranges from 120V DC to 132V DC. There is an isolation between channels and bus at 1780V AC. Its dimensions are 125mm (width) x 47.5mm (depth) x 141.5mm (height). It weighs 0.22kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems. Discontinued by Schneider Electric; the manufacturer's successor is NTSDAO0415K. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of productModicon Momentum automation platform
Product or component typeDiscrete triac I/O base AC
Group of channels1 group of 10 inputs; 1 group of 8 outputs
Discrete input number10
Discrete input logicPositive
Discrete output number8
Discrete output logicPositive

Complementary

Network frequency47...63 Hz
Input resistance4 kOhm
Protection typeInternal 2 x 2.5 A slow-blow fuses
Isolation between channels and bus1780 V AC
Terminals description PLC n°1(8)IN_DIS#8; (5)IN_DIS#5; (9)IN_DIS#9; (4)IN_DIS#4; (10)IN_DIS#10; (3)IN_DIS#3; (L1)PW; (N)PW; (6)IN_DIS#6; (7)IN_DIS#7; (1)IN_DIS#1; TB; (2)IN_DIS#2
Terminals description PLC n°2(3)OUT_DIS#3; (6)OUT_DIS#6; (1N)PW; (2)OUT_DIS#2; (1L1)PW; (8)OUT_DIS#8; (7)OUT_DIS#7; (1)OUT_DIS#1; (4)OUT_DIS#4; (5)OUT_DIS#5; TB_1
Height141.5 mm
Width125 mm
Depth47.5 mm
Net weight0.22 kg

Environment

Protective treatmentTC
MarkingCE

Downloads & documentation

Official documents from Schneider Electric, downloaded directly from the manufacturer.

Data sheets & manuals

170ADM69051: frequently asked questions

Can I still buy the 170ADM69051 now that it is discontinued?

Yes. Schneider Electric has discontinued the 170ADM69051, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Schneider Electric names the NTSDAO0415K as its successor — we can quote both.

When can 170ADM69051 be shipped?

170ADM69051 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 170ADM69051 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 170ADM69051 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 170ADM69051, subject to availability and destination.
