Schneider Electric 170ADM39030

Discrete I/O module Modicon Momentum - 10I / 8O relay

MPN
170ADM39030
EAN
3595861147652
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Schneider Electric parts? We buy surplus →

What is the Schneider Electric 170ADM39030?

This I/O module is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This discrete relay I/O base DC module offers 1 group of 10 inputs and 2 groups of 4 outputs with positive discrete input logic. It is a module with discrete input voltage ranges from 20V AC to 115V AC and discrete output voltage ranges from 20V DC to 115V DC. There is an isolation between channels and bus at 500V AC. Its dimensions are 125mm (width) x 47.5mm (depth) x 141.5mm (height). It weighs 0.26kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems.

Specifications

Specifications

Range of productModicon Momentum automation platform
Product or component typeDiscrete relay I/O base DC
Group of channels1 group of 10 inputs, 2 groups of 4 outputs
Discrete input number10 conforming to IEC 1131-2 Type 1
Discrete input logicPositive
Discrete input voltage11...30 V DC
Discrete output number8
Discrete output typeRelay normally open
Discrete output voltage20...115 V DC, 24...230 V AC
Protective treatmentTC
[Us] rated supply voltage24 V DC
Input voltage limits- 3...30 V
Network frequency47...63 Hz
Voltage state 0 guaranteed-3...5 V
Voltage state 1 guaranteed11...30 V
Current state 0 guaranteed<= 1.2 mA
Current state 1 guaranteed>= 2.5 mA
Input resistance4 kOhm
Discrete output current<= 0.15 mA 115 V inductive, <= 0.5 mA 115 V resistive, <= 1 mA 24 V inductive, <= 2 mA 24 V resistive, >= 0.005 A 24 V
Maximum leakage current1 mA at 230 V (output circuit)
Mechanical durability30000000 cycles
Electrical durability100000 cycles inductive
Response time10 ms 60 Hz from state 0 to state 1 on output, 10 ms 60 Hz from state 1 to state 0 on output, 2.2 ms from state 0 to state 1 on input, 3.3 ms from state 1 to state 0 on input
Isolation between channels and bus500 V AC
Power dissipation5.5 W, <= 8.5 W
Protection typeWithout protection
Associated fuse rating4 A fast blow input voltage, 8 A slow-blow output voltage per group, 375 mA fast blow operating voltage
MarkingCE
Terminals description PLC n°1(1L+)PW_POS, (3)IN_DIS#3, (9)IN_DIS#9, (1)IN_DIS#1, (8)IN_DIS#8, (6)IN_DIS#6, (2)IN_DIS#2, (7)IN_DIS#7, (4)IN_DIS#4, (L+)PW_POS, (10)IN_DIS#10, (5)IN_DIS#5, (M-)PW_NEG, TB
Terminals description PLC n°2(6)OUT_DIS#6, (2L1)PW, (2)OUT_DIS#2, TB_1, (8)OUT_DIS#8, (7)OUT_DIS#7, (1L+)PW, (4)OUT_DIS#4, (5)OUT_DIS#5, (1)OUT_DIS#1, (3)OUT_DIS#3
Current consumption250 mA at 24 V DC
Depth47.5 mm
Height141.5 mm
Width125 mm
Net weight0.26 kg
Product certificationsUL, CSA
Resistance to electrostatic discharge4 kV contact conforming to IEC 801-2, 8 kV on air conforming to IEC 801-2
Resistance to electromagnetic fields10 V/m 80...1000 MHz conforming to IEC 801-3
Ambient air temperature for operation0…60 °C
Ambient air temperature for storage-40…85 °C
Relative humidity95 % without condensation
Operating altitude<= 5000 m

Packaging

Package 11 PCE, 26.000 cm × 18.000 cm × 9.000 cm (L × W × H), 510.000 g
Package 26 S03, 40.000 cm × 30.000 cm × 30.000 cm (L × W × H), 3.792 kg
