Mitsubishi Electric RE81WH

Mitsubishi MELSEC iQ-R Series Energy measuring

MPN
RE81WH
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric RE81WH?

The Mitsubishi Electric RE81WH is a energy measuring in the MELSEC iQ-R Series. Number of measurement circuits : 1 circuit Phase wire system : Single-phase 2-wire, single-phase 3-wire, 3-phase 3-wire common Measurement items : Current, demanded current, voltage, power, demanded power, reactive power, apparent power, harmonic current, harmonic voltage, frequency, power factor, electric energy, reactive electric energy. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesMELSEC iQ-R Series
CategoryEnergy measuring
OutlineNumber of measurement circuits : 1 circuit Phase wire system : Single-phase 2-wire, single-phase 3-wire, 3-phase 3-wire common Measurement items : Current, demanded current, voltage, power, demanded power, reactive power, apparent power, harmonic current, harmonic voltage, frequency, power factor, electric energy, reactive electric energy

Specifications

Number of measurement circuits1 circuit
Phase wire systemSingle-phase 2-wire, single-phase 3-wire, 3-phase 3-wire common
Instrument rating: Voltage circuit: Single-phase 2-wire, 3-phase 3-wire110V, 220V AC common
Instrument rating: Voltage circuit: Single-phase 3-wire110V AC (between wires 1 and 2, and wires 2 and 3), 220V AC (between wires 1 and 3)
Instrument rating: Current circuit50A, 100A, 250A, 400A, 600A (Dedicated split-type current sensor is used. All values indicate primary current values of current sensor.) 5A (Dedicated 5A current sensor is used. Current transformer (CT) is used in two-step configuration together with the 5A current sensor in order to allow a maximum primary current value setting of 6,000A)
Instrument rating: Frequency50/60Hz (automatic frequency selection)
Main unit tolerances (current sensors not included in tolerance)Current, demanded current : ±1.0% (relative to rated input) Voltage : ±1.0% (relative to rated input) Power, demanded power : ±1.0% (relative to rated input) Reactive power : ±1.0% (relative to rated input) Apparent power : ±1.0% (relative to rated input) Harmonic current : ±2.5% (relative to rated input) Harmonic voltage : ±2.5% (relative to rated input) Frequency : ±1.0% (in 45 to 65Hz range) Po
Data update cycle10 to 10000 ms (able to set in increments of 10 ms)
Transient overvoltageMeasurement circuit: CATⅢ
Commercial frequency withstand voltage2210 V AC for 5 s (between voltage/current input terminals - programmable controller power supply and GND terminals)
Applicable standardsEMC : EN61131-2: 2007, EN61326-1: 2013 Safety standards : EN61131-2: 2007, EN61010-1: 2010 UL61010-1 : 3rd Edition
Power failure backupNon-volatile memory backup (Recorded items: setting values, maximum/minimum values and date/time of occurrence, electric energy (regeneration, consumption), reactive electric energy, periodic electric energy)
Number of occupied I/O points32
External dimensions: Height (H)106mm
External dimensions: Width (W)27.8mm
External dimensions: Depth (D)107.1mm
Weight0.2kg

Specifications

General SpecificationsRefer to the general Specifications of CPU module or remote head module.
