Mitsubishi Electric Q63RP
Mitsubishi MELSEC-Q Series Redundant power supply type
- MPN
- Q63RP
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →
What is the Mitsubishi Electric Q63RP?
The Mitsubishi Electric Q63RP is a redundant power supply type in the MELSEC-Q Series. Input: 24 V DC, output: 5 V DC 8.5 A. Mitsubishi Electric has announced its discontinuation (2029/09 To be end of order) — plan spares now; PartnerPLC also sources it on the surplus market after the end of order. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | MELSEC-Q Series |
| Category | Redundant power supply type |
| Type | DC input |
| Subtype | 24 V DC input |
| Sales status | 2029/09 To be end of order (Mitsubishi Electric) |
| Outline | Input: 24 V DC, output: 5 V DC 8.5 A |
Specifications
| Installation position | Redundant power supply module installation slot |
| Applicable base unit | Q38RB, Q68RB, Q65WRB |
| Input power supply voltage | 24 V DC (-35 %...+30 %) |
| Maximum input power | 65 W |
| Inrush current | 150 A, within 1 ms |
| Rated output current: 5 V DC | 8.5 A |
| Overcurrent protection: 5 V DC | 9.35 A or more |
| Overvoltage protection: 5 V DC | 5.5...6.5 V |
| Efficiency | 65 % or more |
| Allowable momentary power failure time | Within 10 ms (at 24 V DC input) |
| Withstand voltage | Between the input and LG batched terminal and the output and FG batched terminal, 510 V AC per minute (altitude 0...2000 m) |
| Insulation resistance | 10 MΩ or higher by insulation resistance tester |
| Operation indication | LED indication (Normal: ON (green), Error: ON (red)) |
| Fuse | Built-in (user-unchangeable) |
| Contact output section: Application | ERR. contact |
| Contact output section: Rated switching voltage/current | 24 V DC, 0.5 A |
| Contact output section: Minimum switching load | 5 V DC, 1 mA |
| Contact output section: Response time: OFF to ON | 10 ms or less |
| Contact output section: Response time: ON to OFF | 12 ms or less |
| Contact output section: Life: Mechanical | 20 million times or more |
| Contact output section: Life: Electrical | Rated switching voltage/current load: More than 100 thousand times |
| Contact output section: Surge suppressor | None |
| Contact output section: Fuse | None |
| External interface | Terminal block (M3.5 screw) |
| External dimensions: Height | 98 mm |
| External dimensions: Width | 83 mm |
| External dimensions: Depth | 115 mm |
| Weight | 0.60 kg |
Specifications
| General specifications | Refer to the general specifications of the CPU module. |
No matching specifications
