PD-100H Mitsubishi Power monitoring Voltage Transformers (VT)
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Mitsubishi Power monitoring – Instrument Transformers |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can PD-100H be shipped?
PD-100H is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up PD-100H in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for PD-100H and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for PD-100H, subject to availability and destination.
The Mitsubishi Electric PD-100H is a voltage Transformers (VT) in the Power monitoring. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | Power monitoring |
| Category | Voltage Transformers (VT) |
| Type | Less than or equal to 6600V |
Specifications
| Category | Instrument Transformers |
| Group | Voltage Transformers (VT) |
| Circuit voltage | Less than or equal to 6600V |
| Use | General-use meters/Relays |
| Model name | PD-100H |
| Primary voltage (V) | 220 |
| Secondary voltage (V) | 110 |
| Rated burden (VA) | 100 |
| Applicable standards | JIS C 1731-2 / JEC-1201-2007 |
| Accuracy (class) | 1.0・1P |
| Withstand voltage (kV) | 2/－ |
| Frequency (Hz) | Both 50/60 |
| Limit output (VA) | 200 |
| Mass (kg) | 8.5 |
