ME110SSR-MB Mitsubishi Power monitoring MODBUS RTU

MPN: ME110SSR-MB · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Discontinued by Mitsubishi Electric (Factory Automation) — we can still source the original ME110SSR-MB (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Power monitoring – Meters
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

Can I still buy the ME110SSR-MB now that it is discontinued?

Yes. Mitsubishi Electric (Factory Automation) has discontinued the ME110SSR-MB, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can ME110SSR-MB be shipped?

ME110SSR-MB is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up ME110SSR-MB in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for ME110SSR-MB and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for ME110SSR-MB, subject to availability and destination.

The Mitsubishi Electric ME110SSR-MB is a MODBUS RTU in the Power monitoring. Mitsubishi Electric has discontinued it (2024/03 Discontinued); PartnerPLC sources discontinued Mitsubishi parts on the surplus market for maintenance of existing machines. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Power monitoring
Category	MODBUS RTU
Sales status	2024/03 Discontinued (Mitsubishi Electric)

Specifications

Category	Electrical Indicators
Group	Electronic Multi-Measuring Instrument
Model	ME110 Super-S Series (RS-485 (MODBUS RTU) Communication)
Model name	ME110SSR-MB
Phase wire system	3-phase 4-wire, 3-phase 3-wire (3CT, 2CT), 1-phase 3-wire, 1-phase 2-wire (common use)
Rating: Current	5A AC, 1A AC (1A AC is special-purpose item)
Rating: Voltage	3-phase 4-wire : max 277/480V AC 3-phase 3-wire : 110V AC, 220V AC 1-phase 3-wire : 220V AC (110/220V AC) 1-phase 2-wire : 110V AC, 220V AC
Rating: Frequency	50-60Hz
Measuring element: Current (A): Measuring Item	3P4W : A1, A2, A3, AN, A AVG 3P3W, 1P3W : A1, A2, A3 1P2W : A1
Measuring element: Current (A): Class	0.5%
Measuring element: Current demand (DA): Measuring Item	3P4W : DA1, DA2, DA3, DAN, DA AVG 3P3W, 1P3W : DA1, DA2, DA3 1P2W : DA1
Measuring element: Current demand (DA): Class	0.5%
Measuring element: Voltage (V): Measuring Item	3P4W : V12, V23, V31, V AVG (L-L), V1N, V2N, V3N, V AVG (L-N) 3P3W, 1P3W : V12, V23, V31 1P2W : V12
Measuring element: Voltage (V): Class	0.5%
Measuring element: Active power (W): Measuring Item	3P4W : ΣW, W1, W2, W3 3P3W, 1P3W, 1P2W : ΣW
Measuring element: Active power (W): Class	0.5%
Measuring element: Active demand power (DW): Measuring Item	3P4W : ΣDW, DW1, DW2, DW3 3P3W, 1P3W, 1P2W : ΣDW
Measuring element: Active demand power (DW): Class	0.5%
Measuring element: Reactive power (var): Measuring Item	3P4W : Σvar, var1, var2, var3 3P3W, 1P3W, 1P2W : Σvar
Measuring element: Reactive power (var): Class	0.5%
Measuring element: Apparent power (VA): Measuring Item	3P4W : ΣVA, VA1, VA2, VA3
Measuring element: Apparent power (VA): Class	0.5%
Measuring element: Power factor: Measuring Item	3P4W : Σcosφ, cosφ1, cosφ2, cosφ3 3P3W, 1P3W, 1P2W : Σcosφ
Measuring element: Power factor: Class	2.0%
Measuring element: Frequency (Hz): Measuring Item	Hz
Measuring element: Frequency (Hz): Class	0.5%
Measuring element: Active energy (Wh): Measuring Item	Imported, Exported
Measuring element: Active energy (Wh): Class	2.0%
Measuring element: Reactive energy (varh): Measuring Item	Import Capacitive, Import Inductive, Export Capacitive, Export Inductive
Measuring element: Reactive energy (varh): Class	2.0%
Measuring element: Harmonic current (HI): Measuring Item	3P4W : HI1, HI2, HI3, HIN 3P3W, 1P3W : HI1, HI3 1P2W : HI1 THD, h1...h13 (without even number) RMS value and Distortion ratio (max.100%)
Measuring element: Harmonic current (HI): Class	2.5% (Total RMS, 0 to Rated x 60%)
Measuring element: Harmonic voltage (HV): Measuring Item	3P4W : HV1N, HV2N, HV3N 3P3W, 1P3W : HV12, HV23 1P2W : HV12 THD, h1...h13 (without even number) RMS value and Distortion ratio (max.20%)
Measuring element: Harmonic voltage (HV): Class	2.5% (THD, 0 to 20%)
Measuring Method: Instantaneous Value	A, V : RMS calculation, W, var, VA, Wh, varh : Digital multiplication, cosφ: Power ratio calculation, Hz : Zero-cross, HV, HI : FTT
Measuring Method: Demand Value	Thermal type calculation
Display: Display type	LCD with backlight
Display: Number of display digits or segments: Digital section	A, DA, V, W, DW, var, VA, cosφ: 4 digits Hz, HI, HV : 3 digits Wh, varh : 6 digits
Display: Number of display digits or segments: Bar graph	21 Segment-Bar graph, 22 Segment-Indicator
Display: Display update time interval	0.5s / 1s
Transmission function: Transmission type	MODBUS RTU
Transmission function: Transmission speed	2400, 4800, 9600, 19200, 38400bps
Transmission function: Connection method	Multi-drop
Transmission function: Transmission distance	1000m
Transmission function: Number of connectable units	31 units
Response time	Display : 4s or less, Analog output : 4s or less In HI and HV, 10s or less
Power interruption backup	Non volatile memory (Items : setting value, max/min value, active/reactive energy)
VA Consumption: Voltage circuit	0.1VA/phase, 0.2VA/phase (at direct input)
VA Consumption: Current circuit	0.1VA/phase
VA Consumption: Auxiliary power circuit	8VA at 110VAC, 9VA at 220VAC, 6W at 100VDC
VA Consumption: Digital input	DC19-30V, under 7mA
Auxiliary power	100 to 240VAC (+10%, -15%) 50/60Hz 100VDC (+10%, -30%)
Weight	0.5kg
Dimensions	110(H) x 110(W) x 98(D)
Enclosure	Thermoplastic self-extinguish (UL94V0)
Operating temperature	-5°C to +50°C (average operating temperature : 35°C or less per day)
Operating humidity	85%RHmax, non condensing
Storage temperature	-20°C to +60°C

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

Electronic Multi-Measuring Instrument User's Manual : Simple version (ME110SS Series) (IB63661E--)	PDF · 2.79MB
Electronic Multi-Measuring Instrument User's Manual : Detailed Edition (ME110SS Series) (IB63660-A)	PDF · 9.61MB
