ME96SSEB-MB Mitsubishi Power monitoring MODBUS RTU

MPN: ME96SSEB-MB · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Power monitoring – Meters
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can ME96SSEB-MB be shipped?

ME96SSEB-MB is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up ME96SSEB-MB in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for ME96SSEB-MB and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for ME96SSEB-MB, subject to availability and destination.

The Mitsubishi Electric ME96SSEB-MB is a MODBUS RTU in the Power monitoring. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Power monitoring
Category	MODBUS RTU

Specifications

Category	Electrical Indicators
Group	Electronic Multi-Measuring Instrument
Model	ME96 series economy model
Model name	ME96SSEB-MB
Phase wire system	3-phase 4-wire, 3-phase 3-wire (3CT, 2CT), 1-phase 3-wire, 1-phase 2-wire (common use)
Rating: Current	5A AC, 1A AC (common use)
Rating: Voltage	3-phase 4-wire : max 277/480V AC 3-phase 3-wire : (DELTA) max 220V AC, (STAR) max 440V AC 1-phase 3-wire : max 220/440V AC 1-phase 2-wire : (DELTA) max 220V AC, (STAR) max 440V AC
Rating: Frequency	50/60Hz (common use)
Measuring element: Current (A): Measuring Item	A1, A2, A3, AN, A AVG
Measuring element: Current (A): Class	±0.5%
Measuring element: Current demand (DA): Measuring Item	DA1, DA2, DA3, DAN, DA AVG
Measuring element: Current demand (DA): Class	±0.5%
Measuring element: Voltage (V): Measuring Item	V12, V23, V31, V AVG (L-L), V1N, V2N, V3N, V AVG (L-N)
Measuring element: Voltage (V): Class	±0.5%
Measuring element: Active power (W): Measuring Item	W1, W2, W3, ΣW
Measuring element: Active power (W): Class	±0.5%
Measuring element: Reactive power (var): Measuring Item	var1, var2, var3, Σvar
Measuring element: Reactive power (var): Class	±0.5%
Measuring element: Apparent power (VA): Measuring Item	VA1, VA2, VA3, ΣVA
Measuring element: Apparent power (VA): Class	±0.5%
Measuring element: Power factor (PF): Measuring Item	PF1, PF2, PF3, ΣPF
Measuring element: Power factor (PF): Class	±0.5%
Measuring element: Frequency (Hz): Measuring Item	Hz
Measuring element: Frequency (Hz): Class	±0.2%
Measuring element: Active energy (Wh): Measuring Item	Imported, Exported
Measuring element: Active energy (Wh): Class	class 0.5S (IEC62053-22)
Measuring element: Reactive energy (varh): Measuring Item	Imported lag, Imported lead, Exported lag, Exported lead
Measuring element: Reactive energy (varh): Class	class 1S (IEC62053-24)
Measuring element: Apparent energy (VAh): Measuring Item	Imported + Exported
Measuring element: Apparent energy (VAh): Class	±2.0%
Measuring element: Harmonic current (HI): Measuring Item	Total
Measuring element: Harmonic current (HI): Class	±2.0%
Measuring element: Harmonic voltage (HV): Measuring Item	Total
Measuring element: Harmonic voltage (HV): Class	±2.0%
Measuring element: Operating time (h): Measuring Item	Operating time 1, Operating time 2
Measuring element: Operating time (h): Class	(Reference)
Measuring method: Instantaneous value	A, V: RMS value calculation; W, var, VA, Wh, varh, VAh: Digital multiplication; PF: Power ratio calculation; Hz: Zero-cross; HI, HV: FFT
Measuring method: Demand value	DA: Thermal type calculation
Display: Display type	LCD with LED backlight
Display: Number of display digits or segments: Digital section	First to Third line display: 4 digits, Fourth line display: 6 digits A, DA, V, W, var, VA, PF: 4 digits; Hz: 3 digits; Wh, varh, VAh: 9 digits (6-digit or 12-digit is also available.); Harmonic distortion ratio/content rate: 4 digits; Harmonic RMS value: 4 digits; Operating time: 6 digits
Display: Display update time interval	0.5s, 1s (selectable)
Transmission function: Transmission type	MODBUS RTU
Transmission function: Transmission speed	2400, 4800, 9600, 19200, 38400bps
Transmission function: Connection method	Multi-drop
Transmission function: Transmission distance	1,200m (max)
Transmission function: Number of connectable units	31 units
Connectable Optional Plug-in Module	Cannot connect optional module
Power interruption backup	Use of nonvolatile memory (Items: settings, MAX/MIN value, active energy, reactive energy, apparent energy, operating time)
VA Consumption: Voltage circuit	Each phase: 0.1VA (at 110V AC), 0.2VA (at 220V AC), 0.4VA (at 440V AC)
VA Consumption: Current circuit	Each phase: 0.1VA (5A AC)
VA Consumption: Auxiliary power circuit	4VA (at 110V AC), 5VA (at 220V AC), 3W (at 100V DC)
Auxiliary power	100V to 240V AC (±15%), 100V to 240V DC (-30% +15%)
Weight	0.3 kg
Dimensions	96 (H) × 96 (W) × 36 (D) mm
Mounting method	Embedded
Operating temperature	-5°C to +55°C (Daily average temperature: 35°C or less)
Operating humidity	0% to 85% RH, Non condensing
Storage temperature	-25°C to +75°C (Daily average temperature: 35°C or less)
Storage humidity	0% to 85% RH, Non condensing

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

Electronic Multi-Measuring Instrument User's Manual :Digest version (MODEL:ME96SSHB-MB / ME96SSRB-MB / ME96SSEB-MB) (IB63E69-G)	PDF · 1.37MB
Electronic Multi-Measuring Instrument User's Manual : Detailed Edition (MODEL:ME96SSEB-MB) (IB63E77-C)	PDF · 5.39MB
Electronic Multi-Measuring Instrument ME series MODBUS Interface specifications (LSPM0075-H)	PDF · 5.42MB
