ME-0040C-SS96 Mitsubishi Power monitoring Digital input (4 points)
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Mitsubishi Power monitoring – Meters |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can ME-0040C-SS96 be shipped?
ME-0040C-SS96 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up ME-0040C-SS96 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for ME-0040C-SS96 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for ME-0040C-SS96, subject to availability and destination.
The Mitsubishi Electric ME-0040C-SS96 is a digital input (4 points) in the Power monitoring. ME96SSHB-MB, ME96SSRB-MB, ME96SSHA-MB, ME96SSRA-MB, ME96SSH-MB, ME96SSR-MB. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | Power monitoring |
| Category | Digital input (4 points) |
| Type | CC-Link |
| Outline | ME96SSHB-MB, ME96SSRB-MB, ME96SSHA-MB, ME96SSRA-MB, ME96SSH-MB, ME96SSR-MB |
Specifications
| Category | Electrical Indicators |
| Group | Electronic Multi-Measuring Instrument |
| Model | ME96 series CC-Link communication unit |
| Model name | ME-0040C-SS96 |
| Input functions | Digital input (4 points) |
| Transmission function | CC-Link |
| Used with | ME96SSHB-MB, ME96SSRB-MB, ME96SSHA-MB, ME96SSRA-MB, ME96SSH-MB, ME96SSR-MB |
| Weight | 0.15kg |
| Operating temperature | -5 to +55°C (Average: 35°C or less) |
| Operating humidity | 0 to 85%RH (non condensing) |
| Storage temperature | -25 to +75°C (Average: 35°C or less) |
| Storage humidity | 0 to 85%RH (non condensing) |
Specifications
| Communication | CC-Link Communication |
| No. of occupied stations | 1 Station Remote device station |
| CC-Link version | CC-Link Ver 1.10 / Ver 2.00 |
| Baud rate | 10Mbps / 5Mbps / 2.5Mbps / 625kbps / 156kbps |
| Transmission method | Broadcast polling system |
| Synchronous method | Frame synchronous system |
| Encoding method | NRZI |
| Transmission path format | Bus format (EIA RS485) |
| Transmission format | HDLC |
| Error control system | CRC (X 16 + X 12 + X 5 + 1) |
| Number of connectable units | 42 units (max, remote device station) |
| Remote station numbers (station numbers) | 1 to 64 |
Specifications
| Digital input: Contact capacity | 24V DC (19V DC to 30V DC), 7mA or less |
| Digital input: Signal width | 30ms or more |
