ME-0040MT2-SS96 Mitsubishi Power monitoring MODBUS TCP 2 ports * 2 ports for daisy chain, one IP address.

MPN: ME-0040MT2-SS96 · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Power monitoring – Meters
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can ME-0040MT2-SS96 be shipped?

ME-0040MT2-SS96 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up ME-0040MT2-SS96 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for ME-0040MT2-SS96 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for ME-0040MT2-SS96, subject to availability and destination.

The Mitsubishi Electric ME-0040MT2-SS96 is a MODBUS TCP 2 ports * 2 ports for daisy chain, one IP address. in the Power monitoring. ME96SSHB-MB * Applicable only to firmware version 01.01 or later. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Power monitoring
Category	MODBUS TCP 2 ports * 2 ports for daisy chain, one IP address.
Outline	ME96SSHB-MB * Applicable only to firmware version 01.01 or later.

Specifications

Category	Electrical Indicators
Group	Electronic Multi-Measuring Instrument
Model	ME96 series MODBUS TCP communication unit
Model name	ME-0040MT2-SS96
Transmission function	MODBUS TCP 2 ports * 2 ports for daisy chain, one IP address.
Used with	ME96SSHB-MB * Applicable only to firmware version 01.01 or later.
Weight	0.15kg
Operating temperature	-5 to +55°C (Average: 35°C or less)
Operating humidity	0 to 85%RH (non condensing)
Storage temperature	-25 to +75°C (Average: 35°C or less)
Storage humidity	0 to 85%RH (non condensing)

Specifications

Communication	MODBUS TCP communication
Interface	2 port (10BASE-T/100BASE-TX)
Transmission method	Base band
Maximum segment length	100m
Connector applicable to external wiring	RJ45
Cable: 10BASE-T	Cable compliant with IEEE802.3 10BASE-T standard (Unshielded twisted pair cable (UTP cable), category 3 or higher)
Cable: 100BASE-TX	Cable compliant with IEEE802.3 100BASE-TX standard (Shielded twisted pair cable (STP cable), category 5 or higher)
Protocol	MODBUS TCP (port No.502)
Number of simultaneously connection	Max. 4
Support functions	Auto-negotiation function (automatic recognition of 10BASE-T/100BASE-TX) Auto-MDIX function (automatic recognition of straight cable/cross cable)
