ME-4210-SS96B Mitsubishi Power monitoring Analog output (4 circuits) Pulse/Alarm output (2 points)

MPN: ME-4210-SS96B · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Power monitoring – Meters
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can ME-4210-SS96B be shipped?

ME-4210-SS96B is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up ME-4210-SS96B in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for ME-4210-SS96B and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for ME-4210-SS96B, subject to availability and destination.

The Mitsubishi Electric ME-4210-SS96B is a analog output (4 circuits) Pulse/Alarm output (2 points) in the Power monitoring. ME96SSHB-MB, ME96SSRB-MB. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Power monitoring
Category	Analog output (4 circuits) Pulse/Alarm output (2 points)
Type	Digital input (1 point)
Outline	ME96SSHB-MB, ME96SSRB-MB

Specifications

Category	Electrical Indicators
Group	Electronic Multi-Measuring Instrument
Model	ME96 series Analog, pulse and alarm output unit
Model name	ME-4210-SS96B
Output functions	Analog output (4 circuits) Pulse/Alarm output (2 points)
Input functions	Digital input (1 point)
Used with	ME96SSHB-MB, ME96SSRB-MB
Weight	0.15kg
Operating temperature	-5 to +55°C (Average: 35°C or less)
Operating humidity	0 to 85%RH (non condensing)
Storage temperature	-25 to +75°C (Average: 35°C or less)
Storage humidity	0 to 85%RH (non condensing)

Specifications

Analog output: Output specifications	4mA to 20mA
Analog output: Load resistance	600Ω or less
Analog output: Response time	1 second or less (Hz: 2 seconds or less, HI, HV: 5 seconds or less)
Pulse/Alarm output: Switch type	No-voltage a-contact
Pulse/Alarm output: Contact capacity	35V DC, 0.1A or less
Pulse/Alarm output: Pulse width	0.125s, 0.5s, 1.0s
Digital input: Contact capacity	24V DC (19V DC to 30V DC), 7mA or less
Digital input: Signal width	30ms or more
