M850W Mitsubishi CNC M800W Series
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Mitsubishi CNC – CNC control unit |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can M850W be shipped?
M850W is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up M850W in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for M850W and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for M850W, subject to availability and destination.
The Mitsubishi Electric M850W is a M800W Series in the CNC. 32. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | CNC |
| Category | M800W Series |
| Type | Lathe system |
| Outline | 32 |
Specifications
| Series | M800W Series |
| Machine classification | Lathe system |
| Control unit type | Display/Control unit separated-type |
| Model name | M850W |
| Number of control axes: Max. number of axes (NC axes + Spindles + PLC axes) | 32 |
| Number of control axes: Max. number of NC axes (in total for all the part systems) | 32 |
| Number of control axes: Max. number of spindles | 8 |
| Number of control axes: Max. number of PLC axes | 8 |
| Number of control axes: Max. number of PLC indexing axes | 8 |
| Number of control axes: Number of simultaneous contouring control axes | 8 |
| Number of control axes: Max. number of NC axes in a part system | 12 |
| Max. number of part systems | 8 |
| Max. number of main part systems | 8 |
| Max. number of sub part systems | 8 |
Downloads & documentation
Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.
Data sheets & manuals
| M800/M80/E80/C80 Series Specifications Manual (Function) (IB-1501505) | PDF · 8.91MB |
| M800/M80/E80 Series Instruction Manual (IB-1501274) | PDF · 21.74MB |
