GT27-V4-Z Mitsubishi GOT HMI Option unit
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Mitsubishi GOT HMI – Option units |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can GT27-V4-Z be shipped?
GT27-V4-Z is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up GT27-V4-Z in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for GT27-V4-Z and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for GT27-V4-Z, subject to availability and destination.
The Mitsubishi Electric GT27-V4-Z is a option unit in the GOT HMI. For video input (NTSC/PAL), 4 channels. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | GOT HMI |
| Outline | For video input (NTSC/PAL), 4 channels |
Specifications
| Model | GT27-V4-Z |
| Category | Option units |
| Product name | Video input unit |
| Series name | GOT2000 |
| Video input section *2: Video input format: Color | NTSC format, PAL format (interlaced format) |
| Video input section *2: Video input format: Monochrome | EIA format, CCIR format (interlaced format) |
| Video input section *2: Number of video input channels | 4 channels |
| Video input section *2: Input signal | 1 Vp-p, 75 Ω, composite signal |
| Video input section *2: Display size | 640 x 480 dot 768 x 576 dot *1 720 x 480 dot *1 |
| Video input section *2: Connector for external connection | BNC connector |
| Internal current consumption: 3.3 V DC | 0.32 A |
| Internal current consumption: 5.0 V DC | 0.34 A accompanied with the GT27-IF1000 |
| Weight | 0.34 kg accompanied with the GT27-IF1000 |
| Supported model | GT27 (Excluding GT2705-VTBD.) |
