Mitsubishi Electric GT27-R2-Z
Mitsubishi GOT HMI Option unit
- MPN
- GT27-R2-Z
Discontinued by Mitsubishi Electric (Factory Automation) — we can still source the original GT27-R2-Z (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →
What is the Mitsubishi Electric GT27-R2-Z?
The Mitsubishi Electric GT27-R2-Z is a option unit in the GOT HMI. For analog RGB input, 2 channels (display by channel). Mitsubishi Electric has discontinued it (2019/09 Discontinued); PartnerPLC sources discontinued Mitsubishi parts on the surplus market for maintenance of existing machines. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | GOT HMI |
| Sales status | 2019/09 Discontinued (Mitsubishi Electric) |
| Outline | For analog RGB input, 2 channels (display by channel) |
Specifications
| Model | GT27-R2-Z |
| Category | Option units |
| Product name | RGB input unit |
| Series name | GOT2000 |
| RGB input section: Input method | Analog RGB (XGA: 1024 x 768 dot, SVGA: 800 x 600 dot, VGA: 640 x 480 dot) |
| RGB input section: Number of channels | 2 channels *1 |
| RGB input section: Input image signal | 1 Vp-p, 75 Ω |
| RGB input section: Synchronizing signal | TTL、1 kΩ |
| RGB input section: Display size | 1024 x 768 dot (refresh rate 60 Hz) 800 x 600 dot (refresh rate 60, 72, 75 Hz) 640 x 480 dot (refresh rate 60, 72, 75, 85 Hz) |
| RGB input section: Connector for external connection | D-Sub15 pin: female |
| Internal current consumption: 3.3 V DC | 0.49 A |
| Internal current consumption: 5.0 V DC | 0.35 A accompanied with the GT27-IF1000 |
| Weight | 0.33 kg accompanied with the GT27-IF1000 |
| Supported model | GT27 (Excluding GT2705-VTBD.) |
No matching specifications
Downloads & documentation
Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.
Data sheets & manuals
- GOT2000 Series Video/RGB Input Unit User's Manual (IB-0800519E-F)
- GOT2000系列 主机使用说明书(硬件篇) (SH-081202CHN-AW)
- GOT2000 Series Connection Manual (Microcomputers, MODBUS/Fieldbus Products, Peripherals) For GT Works3 Version1 (SH-081200ENG-AS)
- GOT2000系列 连接手册(微型计算机/MODBUS/现场总线/周边机器连接篇) 对应GT Works3 Version1 (SH-081208CHN-AS)
GT27-R2-Z: frequently asked questions
Can I still buy the GT27-R2-Z now that it is discontinued?
Yes. Mitsubishi Electric (Factory Automation) has discontinued the GT27-R2-Z, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.
When can GT27-R2-Z be shipped?
GT27-R2-Z is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up GT27-R2-Z in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for GT27-R2-Z and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for GT27-R2-Z, subject to availability and destination.
