GT27-V4R1-Z Mitsubishi GOT HMI Option unit
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Mitsubishi GOT HMI – Option units |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can GT27-V4R1-Z be shipped?
GT27-V4R1-Z is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up GT27-V4R1-Z in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for GT27-V4R1-Z and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for GT27-V4R1-Z, subject to availability and destination.
The Mitsubishi Electric GT27-V4R1-Z is a option unit in the GOT HMI. For video input (NTSC/PAL), 4 channels/analog RGB, 1 channel input. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | GOT HMI |
| Outline | For video input (NTSC/PAL), 4 channels/analog RGB, 1 channel input |
Specifications
| Model | GT27-V4R1-Z |
| Category | Option units |
| Product name | Video/RGB input unit |
| Series name | GOT2000 |
| Video input section *2: Video input format: Color | NTSC format, PAL format (interlaced format) |
| Video input section *2: Video input format: Monochrome | EIA format, CCIR format (interlaced format) |
| Video input section *2: Number of video input channels | 4 channels |
| Video input section *2: Input signal | 1 Vp-p, 75 Ω, composite signal |
| Video input section *2: Display size | 640 x 480 dot 768 x 576 dot *1 , 720 x 480 dot *1 |
| Video input section *2: Connector for external connection | BNC connector |
| RGB input section: RGB input method | Analog RGB (XGA: 1024 x 768 dot, SVGA: 800 x 600 dot, VGA: 640 x 480 dot) |
| RGB input section: Number of video input channels | 1 channel |
| RGB input section: Input image signal | 1 Vp-p, 75 Ω |
| RGB input section: Synchronizing signal | TTL, 1 kΩ |
| RGB input section: Display size | 1024 x 768 dot (refresh rate 60 Hz) 800 x 600 dot (refresh rate 60, 72, 75 Hz) 640 x 480 dot (refresh rate 60, 72, 75, 85 Hz) |
| RGB input section: Connector for external connection | D-Sub15 pin: female |
| Internal current consumption: 3.3VDC | 0.51 A |
| Internal current consumption: 5.0VDC | 0.39 A accompanied with the GT27-IF1000 |
| Weight | 0.36 kg accompanied with the GT27-IF1000 |
| Supported model | GT27 (Excluding GT2705-VTBD.) |
