Home / Mitsubishi Electric (Factory Automation) / Mitsubishi MELSEC-F (FX) Series – Data link/Communication / CL1PSU-2A Mitsubishi MELSEC-F (FX) Series Data link/Communication

Available on request

CL1PSU-2A Mitsubishi MELSEC-F (FX) Series Data link/Communication

MPN: CL1PSU-2A · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Discontinued by Mitsubishi Electric (Factory Automation) — we can still source the original CL1PSU-2A (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi MELSEC-F (FX) Series – Data link/Communication
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

Can I still buy the CL1PSU-2A now that it is discontinued?

Yes. Mitsubishi Electric (Factory Automation) has discontinued the CL1PSU-2A, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can CL1PSU-2A be shipped?

CL1PSU-2A is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up CL1PSU-2A in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for CL1PSU-2A and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for CL1PSU-2A, subject to availability and destination.

The Mitsubishi Electric CL1PSU-2A is a data link/Communication in the MELSEC-F (FX) Series. CC-Link/LT dedicated power supply. Mitsubishi Electric has discontinued it (2025/03 Discontinued); PartnerPLC sources discontinued Mitsubishi parts on the surplus market for maintenance of existing machines. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	MELSEC-F (FX) Series
Category	Data link/Communication
Sales status	2025/03 Discontinued (Mitsubishi Electric)
Outline	CC-Link/LT dedicated power supply

Specifications

Mass (weight)	0.4 kg
Input: Rated voltage	100, 120, 200, 230, and 240 V AC
Input: Rated current	1.2 A /100 V AC 0.7 A/200 V AC
Input: Frequency rating	50/60 Hz
Input: Power fuse	3.15 A
Input: Allowable supply voltage range	85 to 264 V AC
Input: Rush current	Max. 50 A/100 V AC Max. 60 A/200 V AC
Output: Output voltage	24 V DC +10%/-5%
Output: Output current	0.01 A to 2 A Derating occurs according to the ambient temperature and power voltage [Use the module in a proper range so that the total current consumption of each module does not exceed 2 A (except the period immediately after the power is turned on).]
Output: Ripple noise	500 mVp-p or below
External connection method	・Supplies power from outside to dedicated power supply: 3 points (M3 screws) on terminal block ・To communicate and to supply power to CC-Link/LT system: Connector with 4 pins dedicated to CC-Link/LT (2 pcs.)
Allowable instantaneous power failure time	PS2: Operation continues after power failure for 10 ms or less.
Protection class	IP1X
Protection: Overvoltage protection	110 to 160% Drooping characteristic Automatically reset
Protection: Overcurrent protection	27 V to 33 V Output interrupt Not automatically reset

Specifications

Ambient temperature	0 to 55°C (32 to 131°F) when operating and -25 to 70°C (-13 to 158°F) when stored
Ambient humidity	5 to 95% RH (no condensation) when operating/stored
Vibration resistance: When intermittent vibration is present: Frequency: 10 to 57 Hz	Half amplitude: 0.075 mm Sweep Count for X, Y, Z: 10 times (80 min in each direction)
Vibration resistance: When intermittent vibration is present: Frequency: 57 to 150 Hz	Acceleration: 9.8 m/s 2 Sweep Count for X, Y, Z: 10 times (80 min in each direction)
Vibration resistance: When continuous vibration is present: Frequency: 10 to 57 Hz	Half amplitude: 0.035 mm Sweep Count for X, Y, Z: 10 times (80 min in each direction)
Vibration resistance: When continuous vibration is present: Frequency: 57 to 150 Hz	Acceleration: 4.9 m/s 2 Sweep Count for X, Y, Z: 10 times (80 min in each direction)
Shock resistance	147 m/s 2 , 3 times in each of the X, Y and Z directions
Noise resistance	By noise simulator of 1000 Vp-p in noise voltage, 1 μs in noise width, and 25 to 60 Hz in frequency
Dielectric withstand voltage	AC type: 1500 V AC for 1 min DC type: 500 V AC for 1 min
Insulation resistance	Between external terminal batch and ground terminal: 10 MΩ when measured with 500 V DC insulation resistance tester
Working atmosphere	Free from corrosive or flammable gas and excessive conductive dusts
Working altitude	2000 m or less Do not use the PLC under pressure higher than the atmospheric pressure. Doing so may damage the PLC.
Installation location	Inside control panel
Over-voltage category	II or less This category indicates in which area (inside the site) in relation to the public wiring net the equipment is to be connected. Category II applies, for example, to equipment whose power is supplied from a fixed facility. The surge-resistant voltage of equipment rated 300 V is 2,500 V.
Pollution degree	2 or less This index indicates the degree of conductive substances generated in the environment generated in which the module is used. The degree of contamination 2 indicates that contamination is caused by the generation of only non-conductive substances, however, temporary conduction may be caused by accidental condensation.
Grounding	Class D grounding (grounding resistance: 100 Ω or less)
