Mitsubishi Electric BD-N65

Mitsubishi Low-voltage switchgear Magnetic Contactor

MPN
BD-N65
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric BD-N65?

The Mitsubishi Electric BD-N65 is a magnetic Contactor in the Low-voltage switchgear. Representative rating 20A (Break Contact 2-Pole Series DC-2 DC110V) DC Operated NC Main Contact Contactors. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesLow-voltage switchgear
OutlineRepresentative rating 20A (Break Contact 2-Pole Series DC-2 DC110V) DC Operated NC Main Contact Contactors

Specifications

Product SpecificationDC Operated NC Main Contact
Rated Insulation Voltage Ui [V]690
Main Contact AC Rated Operational Current [A] Break Contact: Three-Phase (Making Only, Without Breaking): AC200 to 220V50
Main Contact AC Rated Operational Current [A] Break Contact: Three-Phase (Making Only, Without Breaking): AC380 to 440V35
Main Contact AC Rated Operational Current [A] Break Contact: 2-Pole Single Phase (Making and Breaking): AC220 to 240V50
Main Contact AC Rated Operational Current [A] Break Contact: 1-Pole Single Phase (Making Only, Without Breaking): AC220 to 240V50
Main Contact AC Rated Operational Current [A] Albeit Contact: 1-Pole Single Phase (Making Only, Without Breaking): AC220 to 240V50
Main Contact DC Rated Operational Current [A]: DC Motor (Category DC2,DC4) 2-Pole: DC110V20
Main Contact DC Rated Operational Current [A]: DC Motor (Category DC2,DC4) 2-Pole: DC220V3
Main Contact DC Rated Operational Current [A]: DC Resistive Load (Category DC1) 2-Pole: DC110V30
Main Contact DC Rated Operational Current [A]: DC Resistive Load (Category DC1) 2-Pole: DC220V10
Main Contact Conventional Free Air Thermal Current [A]80
Main Contact Minimal Applicable Load48V 200mA
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC120V6
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V3
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V1.5
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC550V1.2
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC120V10
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC240V8
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC440V5
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC550V5
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC24V3
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC48V1.5
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC110V0.6
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC220V0.3
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC24V10
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC48V8
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC110V5
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC220V1
Auxiliary Contact Conventional Free Air Thermal Current [A]10
Auxiliary Contact Minimal Applicable Load20V 3mA
Contact Arrangements (Valid): Main Contact (Standard)1NO2NC
Contact Arrangements (Valid): Auxiliary Contact (Standard)2NO2NC
Mechanical Durability [Mil.Times]500
Electrical Durability [Mil.Times]: Category AC-3 (Japan)50
Switching Frequency [Times/Hour]: Category AC-31200
Operation Coil Properties: Operating VoltageDC Operated
Operation Coil Properties: Power Consumption [W]24
Operation Coil Properties: Coil Time Constant [ms]80
Functions: Coil Surge Absorbing FunctionNO
Functions: Terminal CoversNO
Functions: Wiring Streamlining TerminalNO
Mounting MethodScrew Mounting
Terminal Screw Size: Main Circuit (Power Side)M6
Terminal Screw Size: Main Circuit (Load Side)M6
Terminal Screw Size: Operating CircuitM4
Terminal Screw Size: Operation CoilM4

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

BD-N65: frequently asked questions

When can BD-N65 be shipped?

BD-N65 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up BD-N65 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for BD-N65 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for BD-N65, subject to availability and destination.
