What is the Mitsubishi Electric AJ65SBT2B-64RD3?

The Mitsubishi Electric AJ65SBT2B-64RD3 is a remote I/O in the MELSEC network modules. 4 channels, 3-wire resistance thermometer (Pt100, JPt100, Ni100), conversion speed: 40 ms/channel, 2-piece terminal block type, number of occupied stations: 1 station. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesMELSEC network modules
CategoryRemote I/O
TypeAnalog I/O
SubtypeTemperature input
Outline4 channels, 3-wire resistance thermometer (Pt100, JPt100, Ni100), conversion speed: 40 ms/channel, 2-piece terminal block type, number of occupied stations: 1 station

Specifications

Number of channels4 channels
Digital output: Temperature measured value16-bit signed binary value (-2000...8500)
Measuring method3-wire method
Applicable resistance temperature detectorPt100, JPt100, Ni100
Measured temperature range: Pt100-200...850 ˚C
Measured temperature range: JPt100-180...600 ˚C
Measured temperature range: Ni100-60...180 ˚C
Range changing: Pt100-20...120 ˚C / 0...200 ˚C / -200...850 ˚C
Range changing: JPt100-20...120 ˚C / 0...200 ˚C / -180...600 ˚C
Range changing: Ni100―
Temperature detecting output current1 mA
Resolution0.1 ˚C
AccuracyAccuracy (゚C) = (Conversion accuracy) + (Allowable difference of resistance temperature detector used)
Conversion accuracy: Pt100: -200...850 ゚C±0.5 ˚C (ambient temperature: 25±5 ゚C), ±1.4 ˚C (ambient temperature: 0...55 ゚C)
Conversion accuracy: Pt100: -20...120 ゚C±0.2 ˚C (ambient temperature: 25±5 ゚C), ±0.6 ˚C (ambient temperature: 0...55 ゚C)
Conversion accuracy: Pt100: 0...200 ゚C±0.2 ˚C (ambient temperature: 25±5 ゚C), ±0.6 ˚C (ambient temperature: 0...55 ゚C)
Conversion accuracy: JPt100: -180...600 ゚C±0.4 ˚C (ambient temperature: 25±5 ゚C), ±1.0 ˚C (ambient temperature: 0...55 ゚C)
Conversion accuracy: JPt100: -20...120 ゚C±0.2 ˚C (ambient temperature: 25±5 ゚C), ±0.6 ˚C (ambient temperature: 0...55 ゚C)
Conversion accuracy: JPt100: 0...200 ゚C±0.2 ˚C (ambient temperature: 25±5 ゚C), ±0.6 ˚C (ambient temperature: 0...55 ゚C)
Conversion accuracy: Ni100: -60...180 ゚C±0.2 ˚C (Ambient temperature: 25±5 ゚C), ±0.5 ˚C (Ambient temperature: 0...55 ゚C)
Conversion speed40 ms/channel
Disconnection detectionAvailable (each channel independent)
Isolation methodBetween communication system terminal and all RTD input terminals: photocoupler isolation Between power supply system terminal and all all RTD input terminals: transformer isolation Between channels: non-isolation
Dielectric withstand voltageBetween all power supply and communication system terminals and all RTD input terminals: 500 V AC for 1 minute
Station typeRemote device station (Ver. 1 remote device station)
Number of occupied stations1 station
Module power supply: Voltage24 V DC (20.4...28.8 V DC)
Module power supply: Current0.14 A (at 24 V DC)
Module power supply: Inrush current1.7 A, 2.4 ms
External interfaceCommunication part, module power supply part: 7-point two-piece terminal block (M3 screw) I/O part: 18-point two-piece terminal block (M3 screw)
Communication cableCC-Link dedicated cable
External dimensions: Height50 mm
External dimensions: Width122 mm
External dimensions: Depth54 mm
Weight0.25 kg

Specifications

Operating ambient temperature0...55 ˚C
Storage ambient temperature-20...75 ˚C
Operating ambient humidity10...90 %RH, non-condensing
Storage ambient humidity10...90 %RH, non-condensing
Vibration resistance: Compliant with JIS B 3502 and IEC 61131-2: Under intermittent vibrationFrequency: 5...8.4 Hz, Half amplitude: 3.5 mm Frequency: 8.4...150 Hz, Constant acceleration: 9.8 m/s 2 Sweep count: 10 times each in X, Y, Z directions
Vibration resistance: Compliant with JIS B 3502 and IEC 61131-2: Under continuous vibrationFrequency: 5...8.4 Hz, Half amplitude: 1.75 mm Frequency: 8.4...150 Hz, Constant acceleration: 4.9 m/s 2
Shock resistanceCompliant with JIS B 3502 and IEC 61131-2 (147 m/s 2 , 3 times each in 3 directions X, Y, Z)
Operating atmosphereNo corrosive gases
Operating altitude0...2000 m
Installation locationInside a control panel
Overvoltage categoryII or less
Pollution degree2 or less
