Danfoss 4T8DK5

HOSE FTG, 4T/05, DKL-M/08, CS, STR

MPN: 4T8DK5
Category: Thermoplastic hydraulic hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 4T8DK5?

Danfoss HOSE FTG, 4T/05, DKL-M/08, CS, STR, manufacturer part number 4T8DK5. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	1.850
A dimension MM	47.000
Angle shape	Straight
Brand	Synflex Optimum by Danfoss
Compatible hose ID IN	0.310
Compatible hose ID MM	7.938
Construction Style	Crimp
End size 1	-8
End type 1	24 deg. tube port light duty
Finish plating	Dura-Kote
Hex size 1 IN	0.669
Hex size 1 MM	17.000
Hose cut off factor IN	0.910
Hose cut off factor MM	23.100
Hose size	-5
Inside diameter IN	0.210
Inside diameter MM	5.300
Product height in	0.790
Product height mm	20.066
Product length in	1.850
Product length mm	46.990
Product material	Carbon steel
Product width in	0.790
Product width mm	20.066 mm
Thread sealant	No
Thread size 1	M16x1.5
Working pressure max BAR	250
Working pressure max PSI	3650
