Danfoss 4T8DL4

HOSE FTG, 4T/04, DKOL/08, CS, STR

MPN: 4T8DL4
Category: Thermoplastic hydraulic hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 4T8DL4?

Danfoss HOSE FTG, 4T/04, DKOL/08, CS, STR, manufacturer part number 4T8DL4. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	1.900
A dimension MM	48.200
Angle shape	Straight
Compatible hose ID IN	0.250
Compatible hose ID MM	6.350
Construction Style	Crimp
End size 1	-8
End type 1	24 deg. DKO swivel light duty
Finish plating	Dura-Kote
Hex size 1 IN	0.748
Hex size 1 MM	19.000
Hose cut off factor IN	0.980
Hose cut off factor MM	24.800
Hose size	-4
Inside diameter IN	0.170
Inside diameter MM	4.200
Product material	Carbon steel
Seal material	Nitrile (NBR)
Thread sealant	No
Thread size 1	M16x1.5
Working pressure max BAR	275
Working pressure max PSI	4000
