Danfoss 4T10FJB8

HOSE FTG, 4T/08, JIC-F/10, CS, 90D

MPN: 4T10FJB8
Category: Thermoplastic hydraulic hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 4T10FJB8?

Danfoss HOSE FTG, 4T/08, JIC-F/10, CS, 90D, manufacturer part number 4T10FJB8. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	2.710
A dimension MM	68.800
Angle shape	90 Degree
Compatible hose ID IN	0.500
Compatible hose ID MM	12.700
Construction Style	Crimp
Drop dimension IN	1.210
Drop dimension MM	30.8
End size 1	-10
End type 1	Female 37 degree swivel
Finish plating	Zinc plating
Hex size 1 IN	1.063
Hex size 1 MM	27.0
Hose cut off factor IN	1.620
Hose cut off factor MM	41.000
Hose size	-8
Inside diameter IN	0.3800
Inside diameter MM	9.6000
Product height in	2.480
Product height mm	63.000
Product length in	3.346
Product length mm	85.000
Product material	Carbon steel
Product width in	1.181
Product width mm	30.000 mm
Thread sealant	No
Thread size 1	7/8-14 UNF
Working pressure max BAR	350.00
Working pressure max PSI	5100.00

4T10FJB8: frequently asked questions

When can 4T10FJB8 be shipped?

4T10FJB8 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 4T10FJB8 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 4T10FJB8 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 4T10FJB8, subject to availability and destination.
