Danfoss 4T10FJB10

HOSE FTG, 4T/10, JIC-F/10, CS, 90D

MPN: 4T10FJB10
Category: Thermoplastic hydraulic hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 4T10FJB10?

Danfoss HOSE FTG, 4T/10, JIC-F/10, CS, 90D, manufacturer part number 4T10FJB10. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	2.690
A dimension MM	68.400
Angle shape	90 Degree
Compatible hose ID IN	0.620
Compatible hose ID MM	15.875
Construction Style	Crimp
Drop dimension IN	1.210
Drop dimension MM	30.8
End size 1	-10
End type 1	Female 37 degree swivel
Finish plating	Protective oil
Hex size 1 IN	1.063
Hex size 1 MM	27.0
Hose cut off factor IN	1.547
Hose cut off factor MM	39.300
Hose size	-10
Inside diameter IN	0.4600
Inside diameter MM	11.7000
Product height in	2.126
Product height mm	54.000
Product length in	3.543
Product length mm	90.000
Product material	Carbon steel
Product width in	1.181
Product width mm	30.000 mm
Thread sealant	No
Thread size 1	7/8-14 UNF
Working pressure max BAR	350.00
Working pressure max PSI	5100.00
