Danfoss 1AT24FL20

HOSE FTG, 1A/20, C61/24, CS, STR

MPN: 1AT24FL20
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1AT24FL20?

Danfoss HOSE FTG, 1A/20, C61/24, CS, STR, manufacturer part number 1AT24FL20. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146128270
A dimension IN	4.090
A dimension MM	104.000
Angle shape	Straight
Brand	Aeroquip by Danfoss
Compatible hose ID IN	1.250
Compatible hose ID MM	31.800
Construction Style	Crimp
End size 1	-24
End Type 1	Split flange code 61
Finish plating	Dura-Kote
Hose cut off factor IN	2.540
Hose cut off factor MM	64.500
Hose size	-20
Inside diameter IN	1.050
Inside diameter MM	26.600
Product height in	2.410
Product height mm	61.214
Product length in	4.090
Product length mm	103.886
Product material	Carbon steel
Product width in	2.410
Product width mm	61.214
Series	1A/Z Series
Working pressure max BAR	206
Working pressure max PSI	2950
Working temperature max C	150
Working temperature max F	302
Working temperature min C	-40
Working temperature min F	-40
