Danfoss 1A12BT12

HOSE FTG, 1A/12, BSPT-M/12, CS, STR

MPN: 1A12BT12
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1A12BT12?

Danfoss HOSE FTG, 1A/12, BSPT-M/12, CS, STR, manufacturer part number 1A12BT12. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146168177
A dimension IN	2.800
A dimension MM	71.100
Angle shape	Straight
Brand	Aeroquip by Danfoss
Compatible hose ID IN	0.750
Compatible hose ID MM	19.000
Construction Style	Crimp
End size 1	-12
End Type 1	Male pipe BSPT
Finish plating	Dura-Kote
Hex size 1 IN	1.180
Hex size 1 MM	29.972
Hex size 2 MM	30.000
Hose cut off factor IN	1.610
Hose cut off factor MM	40.900
Hose size	-12
Inside diameter IN	0.610
Inside diameter MM	15.500
Product height in	1.560
Product height mm	39.624
Product length in	2.800
Product length mm	71.120
Product material	Carbon steel
Product width in	1.560
Product width mm	39.624
Proposition 65	Cancer and Reproductive Harm
Series	1A/Z Series
Thread sealant	No
Thread size 1	R 3/4
Working temperature max C	150
Working temperature max F	302
Working temperature min C	-40
Working temperature min F	-40
