Danfoss 1A12DK8AH

HOSE FTG, 1A/08, DKL-M/12, CS, STR

MPN: 1A12DK8AH
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1A12DK8AH?

Danfoss HOSE FTG, 1A/08, DKL-M/12, CS, STR, manufacturer part number 1A12DK8AH. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	2.200
A dimension MM	56.000
Angle shape	Straight
Brand	Aeroquip by Danfoss
Compatible hose ID IN	0.500
Compatible hose ID MM	12.700
Construction Style	Crimp
End connection torque	55-70 lb-ft(75-95 Nm)
End size 1	-12
End Type 1	24 deg. tube port light duty
Finish plating	Dura-Kote
Hex size 1 IN	0.940
Hex size 1 MM	23.876
Hex size 2 MM	24.000
Hose cut off factor IN	1.040
Hose cut off factor MM	26.300
Hose size	-8
Inside diameter IN	0.380
Inside diameter MM	9.600
Product height in	1.220
Product height mm	30.988
Product length in	2.200
Product length mm	55.880
Product material	Carbon steel
Product width in	1.220
Product width mm	30.988
Series	1A/Z Series
Thread sealant	No
Thread size 1	M22x1.5
Working pressure max BAR	160.00
Working pressure max PSI	2300.00
Working temperature max C	150
Working temperature max F	302
Working temperature min C	-40
Working temperature min F	-40
