Danfoss 14211-12-08Z

HOSE NIPPLE ASSY,2P/08,ORS-M/12,CS,STR

MPN: 14211-12-08Z
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 14211-12-08Z?

Danfoss HOSE NIPPLE ASSY,2P/08,ORS-M/12,CS,STR, manufacturer part number 14211-12-08Z. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	2.640
A dimension MM	67.000
Angle shape	Straight
Brand	Winner by Danfoss
Compatible hose ID IN	0.500
Compatible hose ID MM	12.700
Construction Style	Crimp
End connection torque	65-70 lb-ft(88-95 Nm)
End size 1	-12
End Type 1	Male ORFS
Finish plating	Zinc plating
Hex size 2 MM	32.000
Hose cut off factor IN	1.400
Hose cut off factor MM	35.500
Hose size	-8
Inside diameter IN	0.390
Inside diameter MM	10.000
Product height in	1.450
Product height mm	36.830
Product length in	2.640
Product length mm	67.056
Product material	Carbon steel
Product width in	1.260
Product width mm	32.004
Proposition 65	Cancer and Reproductive Harm
Seal material	Nitrile (NBR)
Series	Winner 2-Piece
Thread size 1	1 3/16-12 UN
Working pressure max BAR	414
Working pressure max PSI	6000
Working temperature max C	100
Working temperature max F	212
Working temperature min C	-40
Working temperature min F	-40
