What is the B&R 4XP0000.00-K38?
X2X Handheld
for CNC applications
Handheld - X2X for CNC applications 12 function keys, start and stop button, 3 selector switches, emergency stop, CNC encoder wheel, enable switch, spiral cable
Specifications
General information
| LEDs | 1x round (green), 1x error (red) |
Interfaces
| X2X – Type | X2X slave |
| X2X – Variant | 12-pin spiral cable |
| X2X – Internal bus power supply | Yes |
| X2X – Distance between 2 stations | Must be used as the last station. Cannot be routed further. |
| X2X – Electrical isolation | Yes |
Keys
| Emergency switch-off | 2 normally closed |
| Membrane keys | 12x |
Features
| Pushbuttons – Quantity | 2x |
| Pushbuttons – Contact element | 1x N.O. |
| Pushbuttons – Front ring | Metal plated |
| Pushbuttons – Evaluation | X2X |
| Selector switch – Quantity | 4x |
| Selector switch – Evaluation | X2X |
| Selector switch – Limit | 3x 15 positions ; 1x 7 positions |
| Incremental encoders – Type | ESO77-4-0100-05-D-RK |
| Incremental encoders – Evaluation | X2X |
Electrical properties
| Nominal voltage | 24 VDC ±25% |
| Inrush current | Max. 20 A for < 1 ms |
| Power consumption | 170 mA |
Operating conditions
| Degree of protection per EN 60529 | IP54 |
Ambient conditions
| Temperature – Operation | 0 to 50°C |
| Temperature – Storage | -20 to 60°C |
| Temperature – Transport | -20 to 60°C |
| Relative humidity – Operation | T ≤ 40°C: 5 to 90%, non-condensing; T > 40°C: <75%, non-condensing |
| Relative humidity – Storage | T ≤ 40°C: 5 to 90%, non-condensing; T > 40°C: < 75%, non-condensing |
| Relative humidity – Transport | T ≤ 40°C: 5 to 90%, non-condensing; T > 40°C: < 75%, non-condensing |
| Elevation – Operation | Max. 3000 m |
Mechanical properties
| Housing – Material | Metal |
| Front – Material | Polyester |
| Front – Frame | Naturally anodized aluminum |
| Front – Design | B&R standard |
| Front – Gasket | Flat gasket around display front |
| Dimensions – Width | 280 mm |
| Dimensions – Height | 140 mm |
| Dimensions – Depth | 86.2 mm |
| Weight | 430 g |
Downloads & documentation
Official documents from B&R, downloaded directly from the manufacturer.
Data sheets & manuals
CAD & dimension drawings
