B&R 1TGMPDB.20-01

Communicate with the database without having to deal with…

MPN: 1TGMPDB.20-01
Category: Technology Guard

Price and lead time confirmed within 1 business day

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
100% positive eBay feedback
Ships via

Have spare B&R parts? We buy surplus →

What is the B&R 1TGMPDB.20-01?

Communicate with the database without having to deal with SQL database language

Start queries via easy-to-operate configuration interface

mapp Database enables the simple integration of SQL databases into an application. It does not matter whether the database is located on a PC on the machine or whether the data is collected centrally in the company network.

Typical applications:

Saving a machine's production data to a database

Performing quality checks based on the information in the database

Operating machines with production and machine parameters from a database

Functional scope:

When setting up mapp Database, the user defines the connection parameters to the database in the configuration, for example the port number or IP address of the database. Queries can then be defined that can be used at runtime to create tables or add, delete and adjust entries. The user can create the queries via a simplified configuration interface and therefore does not need any SQL knowledge. Alternatively, it is possible to work directly with SQL queries.

Specifications

General information

System requirements – Automation Studio	4.3.3 or later
System requirements – Automation Runtime	B4.34 or later
System requirements – mapp Technology Package	mapp Services
Certifications – CRA (Cyber Resilience Act)	In preparation
Single-user license	Runtime license
Basic package license	1TGMPDB.20-01
Behavior if license missing	License violation indicated by red blinking LED

Accessories

Required accessories (order separately)

1TGMPSRV.00-01

Technology Guard — Creating alarm, user and recipe management; Visual display of alarm, user and recipe management; Modifying the hardware configuration at ru…

Optional accessories (7)

X20CMR111	Other functions — Measurement and evaluation of the ambient conditions in the control cabinet; Recording ambient conditions; Recording operating hours and po…
X20CMR100	Other functions — Measurement and evaluation of the ambient conditions in the control cabinet; Recording ambient conditions; Recording operating hours and po…
X20CMR011	Other functions — Measurement and evaluation of the ambient conditions in the control cabinet; Recording ambient conditions; Recording operating hours and po…
X20cCMR011	Other functions — Measurement and evaluation of the ambient conditions in the control cabinet; Recording ambient conditions; Recording operating hours and po…
0TGF016.01	Technology Guard — Technology Guard (MSD) with integrated flash drive, 16 GB (MLC)
0TG1000.02	Technology Guard — Technology Guard (HID)
0TG1000.01	Technology Guard — Technology Guard (MSD)
