B&R 1TGMPDATA.10-01
Data safely saved even during power failures
- MPN
- 1TGMPDATA.10-01
- Category
- Technology Guard
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the B&R 1TGMPDATA.10-01?
Data safely saved even during power failures
Export logged data to a data storage device
Save data in CSV or PDF format
MpData makes it possible for users to back up values of defined process variables (PVs). This data is stored in .csv files.
Functional scope:
Which process variables are logged is defined when setting up the component. Different modes can be used to record the data. mapp Data can record variables based on time, after a value change or when a defined trigger occurs. The logged data can be displayed in an HMI application as a table. In addition, mapp Data can display statistical data for each process variable, for example the mean value or standard deviation. All data can be stored with password protection to prevent unauthorized access. The collected data can be exported to a USB flash drive, for example, as a CSV or PDF file.
Specifications
General information
| System requirements – Automation Studio | 4.3.3 or later |
| System requirements – Automation Runtime | B4.34 or later |
| Certifications – CRA (Cyber Resilience Act) | In preparation |
| Single-user license | Runtime license |
| Behavior if license missing | License violation indicated by red blinking LED |
Accessories
Required accessories (order separately)
| 1TGMPSRV.00-01 | Technology Guard — Creating alarm, user and recipe management; Visual display of alarm, user and recipe management; Modifying the hardware configuration at ru… |
Optional accessories (7)
| X20CMR111 | Other functions — Measurement and evaluation of the ambient conditions in the control cabinet; Recording ambient conditions; Recording operating hours and po… |
| X20CMR100 | Other functions — Measurement and evaluation of the ambient conditions in the control cabinet; Recording ambient conditions; Recording operating hours and po… |
| X20CMR011 | Other functions — Measurement and evaluation of the ambient conditions in the control cabinet; Recording ambient conditions; Recording operating hours and po… |
| X20cCMR011 | Other functions — Measurement and evaluation of the ambient conditions in the control cabinet; Recording ambient conditions; Recording operating hours and po… |
| 0TGF016.01 | Technology Guard — Technology Guard (MSD) with integrated flash drive, 16 GB (MLC) |
| 0TG1000.02 | Technology Guard — Technology Guard (HID) |
| 0TG1000.01 | Technology Guard — Technology Guard (MSD) |
Downloads & documentation
Official documents from B&R, downloaded directly from the manufacturer.
Certificates (1)
1TGMPDATA.10-01: frequently asked questions
When can 1TGMPDATA.10-01 be shipped?
1TGMPDATA.10-01 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 1TGMPDATA.10-01 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 1TGMPDATA.10-01 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1TGMPDATA.10-01, subject to availability and destination.
