SERVOMOTOR MSM019B-0300-NN-M5-MH1
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Motors for Small Modules SMS |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can R911344212 be shipped?
R911344212 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up R911344212 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for R911344212 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for R911344212, subject to availability and destination.
The maintenance-free motors MSM are available in five sizes up to a mechanical continuous power of 750 watt. The high power density with a short overall length and minimized flange dimensions allow their use in the most diverse applications. The motors in protection type IP54 are equipped with an absolute encoder and can be delivered with or without holding brakes. They are ideal for use with IndraDrive Cs control devices with 3 AC 230 V power supply.
Smooth shaft or keyway
Cable connection with circular connector M17
Multi-turn absolute encoder
Highly dynamic
High power density
Ultra-compact synchronous servo motors MSM up to 7.1 Nm for connection to IndraDrive Cs
Smooth shaft without shaft seal
Multi-turn absolute encoder M5 (20 Bit, absolute encoder functionality only possible with buffer battery)
Cooling: natural convection
Protection type IP54 (shaft IP40)
With or without holding brake
Metal round connector M17
Specifications
Specifications
| Maximum torque [Nm] | 0.95 |
| Maximum speed [rpm] | 5000.0 |
| Brake type | electrically releasing, 1.27 Nm |
| Flange size [mm] | 38 |
| Cooling type | Self-cooling |
| Motor type | with holding brake |
| Rotor inertia (with brake) value [kg/m²] | 0.0000053 |
| Encoder design | Optical encoder, multiturn absolute (20 bit) |
| electrical connection | Cable connection, circular connector M17 |
| Standstill torque (int. cooling) 60k [Nm] | 0.32 |
| Weight [kg] | 0.94 |
