Bosch Rexroth R911344211

SERVOMOTOR MSM019B-0300-NN-M5-MH0

MPN: R911344211
Category: Motors for Small Modules SMS

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Bosch Rexroth parts? We buy surplus →

What is the Bosch Rexroth R911344211?

The maintenance-free motors MSM are available in five sizes up to a mechanical continuous power of 750 watt. The high power density with a short overall length and minimized flange dimensions allow their use in the most diverse applications. The motors in protection type IP54 are equipped with an absolute encoder and can be delivered with or without holding brakes. They are ideal for use with IndraDrive Cs control devices with 3 AC 230 V power supply.

Smooth shaft or keyway

Cable connection with circular connector M17

Multi-turn absolute encoder

Highly dynamic

High power density

Ultra-compact synchronous servo motors MSM up to 7.1 Nm for connection to IndraDrive Cs

Smooth shaft without shaft seal

Multi-turn absolute encoder M5 (20 Bit, absolute encoder functionality only possible with buffer battery)

Cooling: natural convection

Protection type IP54 (shaft IP40)

With or without holding brake

Metal round connector M17

Specifications

Maximum torque [Nm]	0.95
Maximum speed [rpm]	5000.0
Flange size [mm]	38
Cooling type	Self-cooling
Motor type	without holding brake
Rotor inertia (without brake) value [kg/m²]	0.0000053
Encoder design	Optical encoder, multiturn absolute (20 bit)
electrical connection	Cable connection, circular connector M17
Standstill torque (int. cooling) 60k [Nm]	0.32
Weight [kg]	0.73
