Bosch Rexroth R02680C012
CONNECTING ANGLE 2D3-200-A2
- MPN
- R02680C012
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Bosch Rexroth R02680C012?
2D and 3D cantilever systems can be set up by the customer with the angle brackets and connection plates of the Small Modules. The performance data of these multi-axis systems and instructions for the quick and easy selection and setup of the appropriate components are provided in the "Documents" folder.
Specifications
Specifications
| Application | 2D cantilever / 3D cantilever |
| Combination of axes | SMS-120/SMS-080 |
| Size of the basic axis | SMS-120 |
| Size of the attached linear axis | SMS-080 |
| Accessories for Small Modules | Angle bracket |
| Type | 2D3/3D2 |
| Maximum travel range smax x-axis [mm] | 1200.0 |
| Maximum travel range smax y-axis [mm] | 200.0 |
| Payload 2D3 x-32 [kg] | 9.89 |
| Payload 3D2 x-10, y-10, y200, z100 [kg] | 5.0 |
| Payload 3D2 x-10, y-10, y200, z200 [kg] | 5.0 |
| Payload 3D2 x-10, y-10, y200, z300 [kg] | 5.0 |
| Weight [kg] | 2.58 |
