Bosch Rexroth R02680C015

CONNECTING ANGLE 2D4-100-A2

MPN: R02680C015
Category: Connection elements for Small Modules SMS

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Bosch Rexroth parts? We buy surplus →

What is the Bosch Rexroth R02680C015?

2D and 3D cantilever systems can be set up by the customer with the angle brackets and connection plates of the Small Modules. The performance data of these multi-axis systems and instructions for the quick and easy selection and setup of the appropriate components are provided in the "Documents" folder.

Specifications

Application	2D cantilever
Combination of axes	SMS-120/SMS-120
Size of the basic axis	SMS-120
Size of the attached linear axis	SMS-120
Accessories for Small Modules	Angle bracket
Type	2D4
Maximum travel range smax x-axis [mm]	1200.0
Maximum travel range smax y-axis [mm]	100.0
Payload 2D4 x-10 [kg]	63.14
Payload 2D4 x-32 [kg]	17.14
Weight [kg]	3.7
