Beckhoff KL3403

Bus Terminal, 3-channel analog input, power measurement, 500 V AC, 1 A, 16 bit

MPN: KL3403
Category: KL3xxx | Analog input

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Beckhoff KL3403?

The KL3403 Bus Terminal enables the measurement of all relevant electrical data of the supply network. The voltage is measured via the direct connection of L1, L2, L3 and N. The current of the three phases L1, L2 and L3 is fed via simple current

Specifications

Number of inputs	3 x current, 3 x voltage
Technology	3-phase power measurement
Measured values	current, voltage, effective power, energy, cos φ, peak values U, I and P, frequency
Measuring voltage	max. 500 V AC 3~ (ULX-N: max. 288 V AC)
Measuring current	max. 1 A, via measuring transformers x A/1 A
Resolution	16 bit (21 bit, internal)
Measurement error/uncertainty	0.5% relative to full scale value (U, I), 1% calculated value
Measuring procedure	true RMS with 64,000 samples/s
Update time	50 ms per measured value preset, free configurable
Electrical isolation	1500 V (K-bus/field potential)
Current consumption power contacts	– (no power contacts)
Current consumption K-bus	typ. 115 mA
Bit width in the process image	input/output: 3 x 16 bit data, 3 x 8 bit control/status
Special features	energy meter, power measurement, true RMS
Weight	approx. 75 g
Operating temperature	-25…+60°C
Storage temperature	-40…+85°C
Relative humidity	95%, no condensation
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4
Protect. rating/installation pos.	IP20/variable
Approvals/markings	CE, UL
Pluggable wiring	for all KSxxxx Bus Terminals
Design form	compact terminal housing with signal LEDs
Material	polycarbonate
Installation	on 35 mm DIN rail, conforming to EN 60715 with lock
Side by side mounting by means of	double slot and key connection
Marking	labeling of the BZxxxx series
Wiring	solid conductor (s), flexible conductor (st) and ferrule (f): spring actuation by screwdriver
Connection cross-section	s: 0.08…2.5 mm², st: 0.08…2.5 mm², f*: 0.14…1.5 mm²
Connection cross-section AWG	s: AWG28…14, st: AWG28…14, f*: AWG26…16
Stripping length	8…9 mm
Current load power contacts	Imax: 10 A
Dimensions (W x H x D)	12 mm x 100 mm x 68 mm
