Beckhoff KL3362

Bus Terminal, 2-channel analog input, voltage, ±10 V, 15 bit, oscilloscope function

MPN: KL3362
Category: KL3xxx | Analog input

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Beckhoff KL3362?

The KL3362 analog input terminal makes it possible to perform non-central preliminary processing of analog values. The input values are digitized with a 14-bit resolution and written into an internal memory. An efficient processor can pre-process the

Specifications

Number of inputs	2 analog, 1 trigger
Power supply	via the K-bus
Signal voltage	-10…+10 V
Technology	high-speed data logger
Internal resistance	> 500 kΩ (IN1-GND, IN2-GND)
Supply voltage	–
Conversion time	100 µs, configurable (10 µs with fast sampling mode)
Resolution	14 bit + sign
Measurement error/uncertainty	±0.5% (relative to full scale value)
Internal memory	32 kbytes
Trigger	configurable
Current consumption power contacts	– (no power contacts)
Current consumption K-bus	typ. 120 mA
Bit width in the process image	input/output: 2 x 16 bit data (2 x 8 bit control/status per channel)
Special features	high-speed analog analysis
Weight	approx. 55 g
Operating temperature	0…55°C
Storage temperature	-25…+85°C
Relative humidity	95%, no condensation
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4
Protect. rating/installation pos.	IP20/variable
Approvals/markings	CE, CCC, UL, ATEX, IECEx
Pluggable wiring	for all KSxxxx Bus Terminals
Ex marking	ATEX: II 3 G Ex ec IIC T4 Gc IECEx: Ex ec IIC T4 Gc
Design form	compact terminal housing with signal LEDs
Material	polycarbonate
Installation	on 35 mm DIN rail, conforming to EN 60715 with lock
Side by side mounting by means of	double slot and key connection
Marking	labeling of the BZxxxx series
Wiring	solid conductor (s), flexible conductor (st) and ferrule (f): spring actuation by screwdriver
Connection cross-section	s: 0.08…2.5 mm², st: 0.08…2.5 mm², f*: 0.14…1.5 mm²
Connection cross-section AWG	s: AWG28…14, st: AWG28…14, f*: AWG26…16
Stripping length	8…9 mm
Current load power contacts	Imax: 10 A
Dimensions (W x H x D)	12 mm x 100 mm x 68 mm
