Beckhoff KL3356

Bus Terminal, 1-channel analog input, measuring bridge, full bridge, 16 bit, high-precision

MPN: KL3356
Category: KL3xxx | Analog input

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Beckhoff KL3356?

The KL3356 analog input terminal permits direct connection of a resistor bridge. An improved input circuit makes the KL3356 significantly more accurate than the KL3351. The ratio between the bridge voltage UD and the supply voltage UREF is determined in

Specifications

Number of inputs	2, for 1 resistor bridge
Power supply	via the K-bus
Signal voltage	UD: -20…+20 mV UREF: -12…+12 V
Signal voltage UD, UREF	-20…+20 mV, -12…+12 V
Technology	strain gauge connection
Internal resistance	> 200 kΩ (UREF), > 1 MΩ (UD)
Power supply UV	via power contacts
Conversion time	250 ms, configurable
Filter	50 Hz, configurable
Resolution	16 bit
Measurement error/uncertainty	±0.01% (relative to full scale value)
Current consumption power contacts	load only
Current consumption K-bus	typ. 85 mA
Bit width in the process image	input: 2 x 16 bit data (2 x 8 bit control/status optional)
Special features	increased measuring accuracy, self-calibration
Weight	approx. 75 g
Operating temperature	0…55°C
Storage temperature	-25…+85°C
Relative humidity	95%, no condensation
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4
Protect. rating/installation pos.	IP20/variable
Approvals/markings	CE, CCC, UL, ATEX, IECEx
Pluggable wiring	for all KSxxxx Bus Terminals
Ex marking	ATEX: II 3 G Ex ec IIC T4 Gc IECEx: Ex ec IIC T4 Gc
Design form	compact terminal housing with signal LEDs
Material	polycarbonate
Installation	on 35 mm DIN rail, conforming to EN 60715 with lock
Side by side mounting by means of	double slot and key connection
Marking	labeling of the BZxxxx series
Wiring	solid conductor (s), flexible conductor (st) and ferrule (f): spring actuation by screwdriver
Connection cross-section	s: 0.08…2.5 mm², st: 0.08…2.5 mm², f*: 0.14…1.5 mm²
Connection cross-section AWG	s: AWG28…14, st: AWG28…14, f*: AWG26…16
Stripping length	8…9 mm
Current load power contacts	Imax: 10 A
Dimensions (W x H x D)	12 mm x 100 mm x 68 mm
