Compare Sensor-Actuator Cables
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Order code (Pepperl+Fuchs part number) | Sheath stripping force | Length | Cable code | Mass |
|---|
| V11-G-1M-PUR-V11-G | 129945 | max. 10 N / 50 mm | 1 m L | Li 9Y 11YM 3 x 0.34 | 49 g |
| V11-G-5M-PVC-V11-W | 129953 | max. 80 N / 300 mm | 5 m L | Li Y YM 3 x 0,34 | 173.83 g |
| V11-G-2M-PVC-V11-W | 129950 | max. 80 N / 300 mm | 2 m L | Li Y YM 3 x 0,34 | 91.96 g |
| V11-G-10M-PVC-V11-W | 129943 | max. 80 N / 300 mm | 10 m L | Li Y YM 3 x 0,34 | 355.8 g |
| V11-G-5M-PUR-V11-G | 129952 | max. 10 N / 50 mm | 5 m L | Li 9Y 11YM 3 x 0.34 | 152 g |
| V11-G-3M-PUR-V11-G | 129951 | max. 10 N / 50 mm | 3 m L | Li 9Y 11YM 3 x 0.34 | 102.38 g |
| V11-G-2M-PUR-V11-G | 129947 | max. 10 N / 50 mm | 2 m L | Li 9Y 11YM 3 x 0.34 | 75 g |
| V11-G-15M-PUR-V11-G | 129944 | max. 10 N / 50 mm | 15 m L | Li 9Y 11YM 3 x 0.34 | 416.48 g |
| V11-G-0,6M-PUR-V11-G | 183713 | max. 10 N / 50 mm | 0.6 m L | Li 9Y 11YM 3 x 0.34 | 36.9 g |
| V11-G-10M-PUR-V11-G | 129942 | max. 10 N / 50 mm | 10 m L | Li 9Y 11YM 3 x 0.34 | 281 g |
| V11-G-5M-PUR | 191108 | max. 10 N / 50 mm | 5 m L | Li 9Y 11YM 3 x 0.34 | 139.55 g |
| V11-W-5M-PUR | 192742 | max. 10 N / 50 mm | 5 m L | Li 9Y 11YM 3 x 0.34 | 142.14 g |
| V11-W-2M-PUR | 126980 | max. 10 N / 50 mm | 2 m L | Li 9Y 11YM 3 x 0.34 | 63.25 g |
| V11-W-10M-PUR | 126979 | max. 10 N / 50 mm | 10 m L | Li 9Y 11YM 3 x 0.34 | 274 g |
| V11-W-15M-PVC | 126974 | max. 80 N / 300 mm | 15 m L | Li Y YM 3 x 0,34 | 474.33 g |
| V11-G-15M-PVC | 126973 | max. 80 N / 300 mm | 15 m L | Li Y YM 3 x 0,34 | 511.24 g |
| V31-GM-2M-PUR-V1-G | 189539 | max. 60 N / 500 mm | 2 m L | Li 9Y 11Y 4 x 0,25 | 71.03 g |
| V1-G-1M-PVC | 183479 | max. 80 N / 300 mm | 1 m L | Li Y YM 4 x 0,34 | 46.2 g |
| V3-GM-5M-PUR-V11-G | 193620 | max. 80 N / 500 mm | 5 m L | Li 9Y 11Y 3 x 0,25 | 139.68 g |
| V3-GM-3M-PUR-V1-G | 118127 | max. 80 N / 500 mm | 3 m L | Li 9Y 11Y 3 x 0,25 | 92.53 g |
| V3S-GM-0,25M-PVC | 183478 | max. 80 N / 300 mm | 0.25 m L | Li YY 3 x 0,25 | 8.66 g |
| V3S-GM-2M-PVC | 241656 | max. 80 N / 300 mm | 2 m L | Li YY 3 x 0,25 | 56 g |
| V31-GM-3M-PUR | 193751 | max. 60 N / 500 mm | 3 m L | Li 9Y 11Y 4 x 0,25 | 69.7 g |
| V3S-GM-5M-PUR | 112041 | max. 80 N / 500 mm | 5 m L | Li 9Y 11Y 3 x 0,25 | 110 g |
Common to all listed parts
| Connector 1: Locking | screw connection |
| Connector 1: Coding | A-coded |
| Lifecycle | Active (current Pepperl+Fuchs product) |
| Operating current | max. 4 A IB |
| Degree of protection | EN 60529 |
| Lead-free | RoHS directive 2011/65/EU |
| Ambient temperature: Plug connector | -40 ... 90 °C (-40 ... 194 °F) |
| Pollution degree | 3 |
