3VA Molded Case Circuit Breakers up to 2000 A, UL / IEC Parts
Compare 3VA Molded Case Circuit Breakers up to 2000 A, UL / IEC
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | product designation / according to UL file | power loss [W] / maximum | Net Weight | operational current — at 55 °C | operational current — at 60 °C |
|---|---|---|---|---|---|
| 3VA5150-6ED41-0AA0 | HEAS | 12 W | 1.185 kg | 47 A | 46 A |
| 3VA5150-6ED11-0AA0 | H5EAS | 4 W | 0.383 kg | 47 A | 46 A |
| 3VA5190-6ED31-1AA0 | HEAM | 21.4 W | 952 g | 84 A | 82 A |
| 3VA5190-6ED31-0AA0 | HEAS | 21.4 W | 933 g | 84 A | 82 A |
| 3VA5460-6EC31-1AA0 | HLAM | 175 W | 5.2 kg | 560 A | 547 A |
| 3VA5460-6EC31-0AA0 | HLAS | 175 W | 4.742 kg | 560 A | 547 A |
| 3VA5460-5GF41-0AA0 | MLAS | 175 W | 6.82 kg | 560 A | 547 A |
| 3VA5460-5GC41-0AA0 | MLAS | 175 W | 6.82 kg | 560 A | 547 A |
| 3VA5460-5EF41-0AA0 | MLAS | 175 W | 6.82 kg | 560 A | 547 A |
| 3VA6115-0KQ31-0AA0 | EDAE | 29 W | 2.2 kg | 143 A | 135 A |
| 3VA6115-0HL41-0AA0 | EDAE | 29 W | 2.821 kg | 145 A | 139 A |
| 3VA5130-5EF31-0AA0 | MEAS | 9.6 W | 1 g | 28 A | 28 A |
| 3VA5130-5ED41-0AA0 | MEAS | 9.6 W | 1.192 g | — | — |
| 3VA5190-5ED21-1AA0 | MEAM | 14.26 W | 621 g | 84 A | 82 A |
| 3VA5190-5ED21-0AA0 | MEAS | 14.26 W | 621 g | 84 A | 82 A |
| 3VA5190-4ED21-1AA0 | SEAM | 14.26 W | 621 g | 84 A | 82 A |
| 3VA5190-4ED21-0AA0 | SEAS | 14.26 W | 621 g | 84 A | 82 A |
| 3VA5260-7ED31-0AA0 | CFAS | 22 W | 2 kg | — | — |
| 3VA5260-6ED61-0AA0 | HFAS | 15 W | 1.9 kg | — | — |
| 3VA5260-6ED41-2AA0 | HFAS | 22 W | 2 800 g | 55.7 A | 54.3 A |
| 3VA5260-6ED41-0AA0 | HFAS | 22 W | 2.7 kg | — | — |
| 3VA5330-7EC61-0AA0 | CJAS | 47 W | 4.95 kg | 282 A | 276 A |
| 3VA5225-6EF31-0AA0 | HFAS | 58 W | 2.032 kg | 242.5 A | 237.5 A |
| 3VA5225-6EC31-1AA0 | HFAM | 58 W | 2 kg | 241 A | 233 A |
Common to all listed parts
| product designation | Molded-case circuit breaker |
| design of the product | System protection |
| design of the load switch / according to UL 489 / Heating, Air Conditioning, and Refrigeration circuit breaker (HACR Type) | Yes |
| arrangement of electrical connectors / for main current circuit | Without connection |
| type of electrical connection / for main current circuit | Without |
| number of CO contacts / for auxiliary contacts | 0 |
| protection class IP / on the front | IP40 |
| reference code / according to IEC 81346-2 | Q |
