Rotary vane variable displacement pumps Parts
Compare Rotary vane variable displacement pumps
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Size [cm³] | Product family | Operating pressure, max. [bar] | Max. flow [l/min] | Weight [kg] |
|---|---|---|---|---|---|
| R901408945 | 10 | PV7...A | 50.0 | 18.0 | 5.57 |
| R901410764 | 10 | PV7...A | 50.0 | 18.0 | 5.57 |
| R901368646 | 10 | PV7...A | 50.0 | 18.0 | 5.57 |
| R901377879 | 10 | PV7...A | 50.0 | 18.0 | 5.57 |
| R900960926 | 10 | PV7...A | 50.0 | 18.0 | 5.12 |
| R900561857 | 10 | PV7...A | 50.0 | 18.0 | 5.12 |
| R901495397 | 10 | PV7...A | 40.0 | 18.0 | 5.12 |
| 0513800238 | 80 | VPV | 210.0 | 144.0 | 58 |
| 0513800248 | 80 | VPV | 210.0 | 144.0 | 58 |
| 0513700218 | 63 | VPV | 210.0 | 113.0 | 58 |
| 0513600214 | 45 | VPV | 210.0 | 81.0 | 58 |
| 0513500254 | 32 | VPV | 210.0 | 57.0 | 30.4 |
| 0513500220 | 32 | VPV | 210.0 | 57.0 | 28 |
| 0513500206 | 32 | VPV | 210.0 | 57.0 | 25.86 |
| 0513400212 | 25 | VPV | 210.0 | 45.0 | 28 |
| 0513300212 | 16 | VPV | 210.0 | 29.0 | 17.82 |
| 0513300202 | 16 | VPV | 210.0 | 29.0 | 15.98 |
| 0513870226 | 164 | VPV | 210.0 | 295.0 | 113.4 |
| 0513860250 | 130 | VPV | 210.0 | 234.0 | 113 |
| 0513300405 | 16 | VPV | 210.0 | 29.0 | 17.7 |
| 0513300403 | 16 | VPV | 210.0 | 29.0 | 16.27 |
Common to all listed parts
| Displacement type | variable |
| Direction of rotation | clockwise rotation |
