3VA Molded Case Circuit Breakers up to 1600 A, IEC Parts
Compare 3VA Molded Case Circuit Breakers up to 1600 A, IEC
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | power loss [W] / maximum | Net Weight | operational current — at 40 °C | adjustable response value setting current (Ir) / of the L-trip / with I2t characteristic — minimum | adjustable response value setting current (Ii) / for I-tripping — minimum |
|---|---|---|---|---|---|
| 3VA1125-4ED32-0AA0 | 8.5 W | 982 g | 25 A | 25 A | 320 A |
| 3VA1125-4ED26-0AA0 | 5.66 W | 691 g | 25 A | 25 A | 320 A |
| 3VA1125-4ED22-0AA0 | 5.66 W | 683 g | 25 A | 25 A | 320 A |
| 3VA1116-4GF42-0AA0 | 38 W | 1.265 kg | 160 A | 112 A | 800 A |
| 3VA1116-4GE46-0AA0 | 38 W | 1.341 kg | 160 A | 112 A | 1 600 A |
| 3VA1110-5EF32-0AA0 | 25 W | 917 g | 100 A | 70 A | 500 A |
| 3VA1110-5EE46-0AA0 | 25 W | 1.29 kg | 100 A | 70 A | 1 000 A |
| 3VA1112-3ED12-0AA0 | 9.37 W | 402 g | 125 A | 125 A | 1 250 A |
| 3VA1120-4EE42-0AA0 | 12 W | 1.216 kg | 20 A | 14 A | 320 A |
| 3VA1120-4EE36-0AA0 | 12 W | 999 g | 20 A | 14 A | 320 A |
| 3VA1112-6EE46-0AA0 | 28.1 W | 1.333 kg | 125 A | 87 A | 1 250 A |
| 3VA1112-6ED42-0AA0 | 28.1 W | 1.258 kg | 125 A | 125 A | 1 250 A |
| 3VA1112-4EF36-0AA0 | 28.1 W | 1.026 kg | 125 A | 87 A | 625 A |
| 3VA1116-3ED32-0AA0 | 38 W | 967 g | 160 A | 160 A | 1 600 A |
| 3VA1112-5ED32-0AA0 | 28.1 W | 980 g | 125 A | 125 A | 1 250 A |
| 3VA1112-5ED26-0AA0 | 18.74 W | 732 g | 125 A | 125 A | 1 250 A |
| 3VA1112-5ED22-0AA0 | 18.74 W | 0.669 kg | 125 A | 125 A | 1 250 A |
| 3VA1112-5ED16-0AA0 | 9.37 W | 422 g | 125 A | 125 A | 1 250 A |
| 3VA1112-4FD42-0AA0 | 28.1 W | 1.277 kg | 125 A | 125 A | 1 250 A |
| 3VA1112-3EE42-0AA0 | 28.1 W | 1.287 kg | 125 A | 87 A | 1 250 A |
| 3VA1108-6MG36-0AA0 | 2.4 W | 0.97 kg | 8 A | — | 128 A |
| 3VA1102-5MG32-0AA0 | 1.5 W | 942 g | 2 A | — | 32 A |
| 3VA1110-3EE32-0AA0 | 25 W | 914.5 g | 100 A | 70 A | 1 000 A |
| 3VA1110-3ED16-0AA0 | 8.33 W | 403 g | 100 A | 100 A | 1 000 A |
Common to all listed parts
| product designation | Molded case circuit breaker |
| mechanical service life (operating cycles) / typical | 20 000 |
| electrical endurance (operating cycles) / at AC-1 / at 380/415 V | 9 000 |
| electrical endurance (operating cycles) / at AC-1 / at 690 V | 6 300 |
| product feature / for neutral conductors / upgradable/retrofittable / short-circuit and overload proof | No |
| ground-fault monitoring version | Without |
| product function — communication function | No |
| product function — other measurement function | No |
