3VA Molded Case Circuit Breakers up to 1600 A, IEC Parts
Compare 3VA Molded Case Circuit Breakers up to 1600 A, IEC
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Net Weight | switching capacity class of the circuit breaker | maximum short-circuit current breaking capacity (Icu) — at 240 V | maximum short-circuit current breaking capacity (Icu) — at 415 V | maximum short-circuit current breaking capacity (Icu) — at 440 V |
|---|---|---|---|---|---|
| 3VA1080-4ED42-0AA0 | 1.191 kg | S | 55 kA | 36 kA | 25 kA |
| 3VA1110-6GD46-0AA0 | 1.17 kg | H | 100 kA | 70 kA | 55 kA |
| 3VA1110-5EF46-0AA0 | 1.266 kg | M | 85 kA | 55 kA | 36 kA |
| 3VA1110-3FD42-0AA0 | 1.228 kg | N | 36 kA | 25 kA | 16 kA |
| 3VA1110-5ED46-0AA0 | 1.275 kg | M | 85 kA | 55 kA | 36 kA |
| 3VA1096-2ED32-0AA0 | 915 g | B | 25 kA | 16 kA | 8 kA |
| 3VA1080-4ED46-0AA0 | 1.292 kg | S | 55 kA | 36 kA | 25 kA |
| 3VA1110-4FF42-0AA0 | 1.2 kg | S | 55 kA | 36 kA | 25 kA |
| 3VA1110-4FE46-0AA0 | 1.17 kg | S | 55 kA | 36 kA | 25 kA |
| 3VA1110-4FE42-0AA0 | 1.203 kg | S | 55 kA | 36 kA | 25 kA |
| 3VA1110-4FD46-0AA0 | 1.17 kg | S | 55 kA | 36 kA | 25 kA |
| 3VA1110-4FD42-0AA0 | 1.2 kg | S | 55 kA | 36 kA | 25 kA |
| 3VA1110-4EF42-0AA0 | 1.157 kg | S | 55 kA | 36 kA | 25 kA |
Common to all listed parts
| product designation | Molded case circuit breaker |
| design of the product | Line protection |
| protection function of the overcurrent release | LI |
| insulation voltage / rated value | 800 V |
| operating voltage / at AC / rated value | 690 V |
| mechanical service life (operating cycles) / typical | 20 000 |
| electrical endurance (operating cycles) / at AC-1 / at 380/415 V | 9 000 |
| electrical endurance (operating cycles) / at AC-1 / at 690 V | 6 300 |
